▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV88-BMJT 3TNV88C-KJPT Engine Type 3-cylinder liquid-cooled diesel, direct injection 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.1 in³ 100.1 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 32.4 hp 34.2 hp PTO Power 25 hp 30.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry type with safety element Dual element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 8.6 gpm 4.8 gpm Steering Flow 5.3 gpm 3.6 gpm Total Hydraulic Flow 13.9 gpm Not Published Overall Hydraulic Pump Flow 13.9 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 10.0 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 1.2 gal Crankcase Capacity 5.1 qt 1.1 gal Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 9.2 gal Front Axle Fluid Capacity 1.2 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional, 2100 rpm Not Published Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2200 lb 2081.2 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) 8F/8R Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Single dry traction clutch Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes; limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges MFWD (4WD) Front Axle Rating 1587 to 3197 lb 1940 lb Drawbar Capacity 562 lb 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 111.2 in Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 57.3 in Wheelbase 68 in 62.6 in Ground Clearance Not Published 13.0 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 93.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 3166 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.00-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27x8.50-15 27X8.5-15 R3 Turf - Rear 41x14.00-20 41X14-20 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 25X8.5-14 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Quick-change attachment carrier Loader Model 300X; 300CX; H160; H165; 300R; 320R D160 Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 84.0 in Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) 1,186 lb Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) 1,704 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
