▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV88-BMJT V1505-E3-D24H Engine Type 3-cylinder liquid-cooled diesel, direct injection Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 4 Displacement 100.1 in³ 91.5 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 32.4 hp 33 hp PTO Power 25 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dual paper element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Indirect injection Alternator 40 A 14.5 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Not Published Implement Flow 8.6 gpm 6.7 gpm Steering Flow 5.3 gpm 3.2 gpm Total Hydraulic Flow 13.9 gpm 9.9 gpm Overall Hydraulic Pump Flow 13.9 gpm 9.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 (optional rear valve) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 8.1 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 4.7 qt Crankcase Capacity 5.1 qt 5.7 qt Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 3.83 gal Front Axle Fluid Capacity 1.2 gal Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2100 rpm None (no mid-PTO) Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published 1786 lb Hitch Lift Capacity (at 24”) 2200 lb 1400 lb Lift Control Type Position control Quarter inching valve ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) Hydrostatic transmission, 3-range No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) 3-range Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) 11.9 mph Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) 9.5 mph Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Dry single plate Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Two-post ROPS (sunshade optional) Steering Hydrostatic power steering Integral type power steering Brakes Wet disk Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Not Published Front Axle Rating 1587 to 3197 lb Not Published Drawbar Capacity 562 lb 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 99.2 in (w/o 3P) (without 3-point hitch) Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 53.7 in Wheelbase 68 in 66.8 in Ground Clearance Not Published 14.6 in Min. Turn Radius without Brakes Not Published 7.9 ft (w/brake) (with brake applied) Height to Top of ROPS 93.3 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 1764 lb (farm tires); 1786 lb (industrial tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models Not Published R1 Agricultural - Front 7.00-14 7-12 R1 Agricultural - Rear 11.2-24 12.4-16 R3 Turf - Front 27x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 13.6-16 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 Not Published R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Not Published Loader Model 300X; 300CX; H160; H165; 300R; 320R LA504 Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in LA504: 82.6 in Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) LA504: 1065 lb Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
