▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 3TNV88-BMJT D1803-CR-E5 Engine Type 3-cylinder liquid-cooled diesel, direct injection Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 100.1 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 32.4 hp 33 hp PTO Power 25 hp 26.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry type, single element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection Alternator 40 A 45 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Not Published Implement Flow 8.6 gpm 6.3 gpm Steering Flow 5.3 gpm 3.8 gpm Total Hydraulic Flow 13.9 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow 13.9 gpm 10.1 gpm (6.3 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 11.1 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 6.3 qt Crankcase Capacity 5.1 qt 7.1 qt Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 6.9 gal Front Axle Fluid Capacity 1.2 gal 4.8 qt ▶ PTO & HitchPTO Type Independent Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2100 rpm Not Published Category, 3-Point Hitch Category 1 SAE Category I Hitch Lift Capacity Not Published 1998 lb Hitch Lift Capacity (at 24”) 2200 lb 1435 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) Hydrostatic transmission (3-range) No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) 3-range Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) 14.1 mph Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) 12.7 mph Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Integral type power steering Brakes Wet disk Mechanical, wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Cast-iron front axle Front Axle Rating 1587 to 3197 lb Not Published Drawbar Capacity 562 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 108.5 in (without 3-point hitch) Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 55.1 in Wheelbase 68 in 63.4 in Ground Clearance Not Published 13.4 in Min. Turn Radius without Brakes Not Published 8.2 ft (with brake applied) Height to Top of ROPS 93.3 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 2778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7.00-14 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27x8.50-15 25X8.50-14 R3 Turf - Rear 41x14.00-20 13.6-16 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 27X8.50-15 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model 300X; 300CX; H160; H165; 300R; 320R LA526 Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 94.8 in Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) 1144.4 lb Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
