▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-BMJT 3TNV86CT-MJT Engine Type 3-cylinder liquid-cooled diesel, direct injection Diesel, turbocharged No. of Cylinders 3 3 Displacement 91.5 in³ 95.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 37.2 hp 38.2 hp PTO Power 30.5 hp 31.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self-bleeding in-line fuel pump, electric shutoff Not Published Alternator 40 A 75 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Implement/steering pump: dual gear pump; eHydro: PV axial-piston hydrostatic pump Implement Flow 8.6 gpm 9.1 gpm Steering Flow 5.3 gpm 6.2 gpm Total Hydraulic Flow 13.9 gpm 15.3 gpm Overall Hydraulic Pump Flow 13.9 gpm 15.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) Open station (OOS): 13.5 gal; Cab: 11.8 gal Coolant Capacity 1.4 gal (open station); 1.8 gal (cab) Open station (OOS): 1.4 gal; Cab: 1.9 gal Crankcase Capacity 5.1 qt 1.1 gal Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 6.8 gal Front Axle Fluid Capacity 1.2 gal 1.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2100 rpm Optional with eHydro (2100 rpm) Category, 3-Point Hitch Category 1 Limited Category I Hitch Lift Capacity 2,530 lb 2,530 lb at hitch ball Hitch Lift Capacity (at 24”) 2,200 lb 2,200 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range (4WD only); PowrReverser 12F/12R (4WD only) PowrReverser 12F/12R (standard); eHydro Hydrostatic-3 Range (optional) No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) PowrReverser: 12F/12R; eHydro: 3 range Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) eHydro: 18.50 mph Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) eHydro: 18.50 mph Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock (traction assist) ▶ Chassis, Steering & ControlsFrame Type Folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Mechanical front wheel drive (MFWD) Front Axle Rating 1,587 to 3,197 lb 3,196 lb Drawbar Capacity Drawbar tongue capacity: 882 lb; maximum static vertical load: 562 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 69.1 in Wheelbase 68 in 68.0 in Ground Clearance 12.2 in (rear axle) 12.2 in Min. Turn Radius without Brakes Not Published 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 93.3 in 93.3 in Height to Top of ROPS (folded) Not Published 72.0 in Height to Top of Cab Model 89.4 in 85.0 in Overall Length 120.2 in (with 3-point hitch) 120.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,900 lb (open station); 3,570 lb (cab) 2,900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.00-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27x8.50-15 27X8.50-15 or 25/10.5LLX15 R3 Turf - Rear 41x14.00-20 41X14-20 or 41X18LL-16.1 R4 Industrial - Front 25x8.50-14 or 27x8.50-15 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System John Deere Quik-Park Tool-free attach-and-park mounting Loader Model 300CX; H160; H165; 300R; 320R 300R; 320R Loader Lift Height H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) H160: 1,360 lb; H165: 1,598 lb; 300R: 1,360 lb; 320R: 1,598 lb (to maximum height at pivot pin) 300R: 1,360 lb; 320R: 1,598 lb (at pivot pin) Loader Breakout Force H160: 2,855 lbf; H165: 3,327 lbf; 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot point) 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
