▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-BMJT 3TNV86CT-KJPT Engine Type 3-cylinder liquid-cooled diesel, direct injection 4-cycle, inline, water-cooled diesel, turbocharged No. of Cylinders 3 3 Displacement 91.5 in³ 95.8 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 37.2 hp 41.6 hp PTO Power 30.5 hp 36.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry type with safety element Dry Fuel System Direct injection, self-bleeding in-line fuel pump, electric shutoff Direct injection Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Two single-section external gear pumps, one either side of the engine Implement Flow 8.6 gpm 5.9 gpm Steering Flow 5.3 gpm 4.4 gpm Total Hydraulic Flow 13.9 gpm 10.3 gpm Overall Hydraulic Pump Flow 13.9 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published Loader mast mounted SCV (optional); 4th/5th SCV (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 9.7 gal Coolant Capacity 1.4 gal (open station); 1.8 gal (cab) 1.3 gal Crankcase Capacity 5.1 qt 1.1 gal Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 9.2 gal Front Axle Fluid Capacity 1.2 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Transmission driven PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional, 2100 rpm Not Published Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity 2,530 lb Not Published Hitch Lift Capacity (at 24”) 2,200 lb 1,670 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range (4WD only); PowrReverser 12F/12R (4WD only) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) 8F/8R Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) 12.9 mph Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) Not Published Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Single dry traction (mechanical) Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges 4WD Front Axle Rating 1,587 to 3,197 lb 1,940 lb Drawbar Capacity Drawbar tongue capacity: 882 lb; maximum static vertical load: 562 lb 1,102 lb (maximum static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 57.3 in Wheelbase 68 in 62 in Ground Clearance 12.2 in (rear axle) 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 93.3 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published Overall Length 120.2 in (with 3-point hitch) 111.2 in ▶ WeightTractor Weight (Base) 2,900 lb (open station); 3,570 lb (cab) 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.00-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 27x8.50-15 27X8.50-15 R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 or 27x8.50-15 25X8.50-14 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System John Deere Quik-Park Quick-change attachment carrier Loader Model 300CX; H160; H165; 300R; 320R D160 Loader Lift Height H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) H160: 1,360 lb; H165: 1,598 lb; 300R: 1,360 lb; 320R: 1,598 lb (to maximum height at pivot pin) 1,186 lb (at pivot point, maximum height) Loader Breakout Force H160: 2,855 lbf; H165: 3,327 lbf; 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot point) 1,704 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
