▶ EngineEngine Manufacturer Yanmar Mahindra Engine Model 3TNV84T-BMJT CE-38 Engine Type 3-cylinder liquid-cooled diesel, direct injection Four-stroke, Naturally Aspirated, Direct Injection, Water Cooled Diesel Engine No. of Cylinders 3 4 Displacement 91.5 in³ 166.7 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 37.2 hp 37.4 hp PTO Power 30 hp 31 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry dual element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct Injection (mCRD fuel-injected) Alternator 40 A 90 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Not Published Implement Flow 8.6 gpm 7.6 gpm Steering Flow 5.3 gpm 4.1 gpm Total Hydraulic Flow 13.9 gpm 11.7 gpm Overall Hydraulic Pump Flow 13.9 gpm 11.7 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal (open station); 11.8 gal (cab) 9 gal Coolant Capacity 5.6 qt (open station); 7.4 qt (cab) 1.85 gal Crankcase Capacity 5.1 qt 2.25 gal Transmission / Hydraulic System Capacity 6.8 gal (eHydro); 6.3 gal (PowrReverser) 8.5 gal Front Axle Fluid Capacity 1.2 gal 2.17 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm @ 2400 rpm Mid-PTO Availability Optional, 2100 rpm Optional, 2000 rpm @ 2500 engine rpm Category, 3-Point Hitch Category 1 CAT I Hitch Lift Capacity Not Published 2646 lb Hitch Lift Capacity (at 24”) 2200 lb Not Published Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) HST No. of Speeds Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Infinite / 3 Ranges Max Travel Speed (Forward) 19 mph (eHydro); 16.4 mph (PowrReverser) 15.05 mph Max Travel Speed (Reverse) 19 mph (eHydro); 16.4 mph (PowrReverser) 14.38 mph Clutch Multiple stage wet disc, 4.4 in (PowrReverser) Damper Differential Lock & Limited Slip Options Mechanical rear differential lock Bevel gears with diff-lock ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS; cab optional; MFWD standard Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk Wet Disc Brake, Mechanical Seat Suspension & Adjustability Not Published mComfort seat (mechanical suspension; adjustable headrest; foldable armrests) Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Center pin Front Axle Rating 1587 to 3197 lb Not Published Drawbar Capacity 562 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 119.3 in Overall Width 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) 63.2 in Wheelbase 68 in 67.7 in Ground Clearance 12.2 in (rear axle) 14.5 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 93.3 in 94.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 89.4 in Not Published ▶ WeightTractor Weight (Base) 2900 lb (open station); 3570 lb (cab) 3130 lb Weight with ROPS and Loader Not Published 4115 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural, R4 Industrial R1 Agricultural - Front 7.00-14 7-16 6PR R1 Agricultural - Rear 11.2-24 11.2-24 4PR R3 Turf - Front 27x8.50-15 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 25x8.50-14 or 27x8.50-15 10-16.5 R4 Industrial - Rear 43x16.00-20 or 15.00-19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX 2638L: Quick-attach adapter included (loader interfaces with compatible attachments via quick-attach system). Loader Model 300X; 300CX; H160; H165; 300R; 320R 2638L (66 in bucket) Loader Lift Height 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in 2638L: 101.4 in Loader Lift Capacity (Full Height) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) 2638L: 1,634 lb Loader Breakout Force 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) 2638L: 2,696 lb ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty
