John Deere 4044M vs John Deere 4052M vs John Deere 4066M | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Adjustable vinyl seat with retractable seat belt; optional premium seat kit with mechanical suspension base
Front Axle Type
Mechanical front wheel drive (MFWD) - Standard
Mechanical front wheel drive (MFWD) - Standard
Mechanical front wheel drive (MFWD) - Standard
Front Axle Rating
(Continuous) 3,307 lb
(Continuous) 3,307 lb
(Continuous) 3,307 lb
Drawbar Capacity
Max vertical load 1,103 lb
Max vertical load 1,103 lb
Max vertical load 1,103 lb
Overall Width
78.2 in
78.2 in
78.2 in
Wheelbase
73 in
73 in
73.0 in
Ground Clearance
Front axle: 15.6 in
Front axle: 15.6 in
Front axle: 15.6 in
Min. Turn Radius without Brakes
9.84 ft (3.0 m)
17.1 ft
17.1 ft
Height to Top of ROPS
100.2 in
100.2 in
100.2 in
Height to Top of ROPS (folded)
80.5 in
80.5 in
80.5 in
Height to Top of Cab Model
Not Published
Not Published
Not Published
Overall Length
130.6 in (with 3-point hitch)
130.6 in (with 3-point hitch)
130.6 in (with 3-point hitch)
Tractor Weight (Base)
3,770 lb (operating weight)
3,770 lb (operating weight)
3,770 lb (operating weight)
Weight with ROPS and Loader
Not Published
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Not Published
Tire Size & Options
R1 Bar, R3 Turf, R4 Industrial
R1 Bar, R3 Turf, R4 Industrial
R1 Bar, R3 Turf, R4 Industrial
R1 Agricultural - Front
8.00-16 (6PR)
8.00-16 (6PR)
8-16 (6PR)
R1 Agricultural - Rear
13.6-28
13.6-28
13.6-28
R3 Turf - Front
27X10.50-15
27X10.50-15
27X10.50-15
R3 Turf - Rear
44X18.00-20 (4PR)
44X18.00-20 (4PR)
44X18.00-20 (4PR)
R4 Industrial - Front
10-16.5 (6PR)
10-16.5 (6PR, R4 Industrial, 2 Position)
10-16.5 (6PR)
R4 Industrial - Rear
16.9-24 (6PR)
16.9-24 (6PR, R4 Industrial, 2 Position)
16.9-24 (6PR)
Quick Attach Loader System
400E loader: a dealer parking kit allows the loader to be attached and detached; without it the loader is fixed and cannot be detached; optional parking stands
400E loader: a dealer parking kit allows the loader to be attached and detached; without it the loader is fixed and cannot be detached; optional parking stands
Quik-Park easy-to-attach/detach loader
Loader Model
400E
400E
400E
Loader Lift Height
400E: 112 in (to pivot pin)
400E: 112 in (to pivot pin)
400E: 112 in (to pivot pin)
Loader Lift Capacity (Full Height)
400E: 2,391 lb (at pivot, full height)
400E: 2,396 lb (at pivot, full height)
400E: 2,396 lb (at pivot, full height)
Loader Breakout Force
400E: 3,853 lbf at pivot point; 2,902 lbf at 500 mm forward of pivot point
400E: 3,853 lbf at pivot; 2,902 lbf at 19.7 in ahead of pivot
400E: 3,853 lbf at pivot; 2,902 lbf at 500 mm forward of pivot
Warranty Length & Coverage
Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
