John Deere 4044M eHydro vs John Deere 4105 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Mechanical front wheel drive (MFWD), standard, all ranges
Front Axle Rating
(Continuous) 3,307 lb
3,197 lb
Drawbar Capacity
Max vertical load 1,103 lb
882 lb
Overall Width
78.2 in
63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires)
Wheelbase
73 in
68 in
Ground Clearance
Front axle: 15.6 in
14.7 in (front axle)
Min. Turn Radius without Brakes
17.1 ft
Not Published
Height to Top of ROPS
100.2 in
87.6 in
Height to Top of ROPS (folded)
80.5 in
Not Published
Height to Top of Cab Model
Not Published
Not Published
Overall Length
130.6 in (with 3-point hitch)
120.2 in (with 3-point hitch)
Tractor Weight (Base)
3,770 lb (operating weight)
2,899 lb (with ROPS, 3-point hitch and all fluids)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 Bar, R3 Turf, R4 Industrial
R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-R24 rear)
R1 Agricultural - Front
8.00-16 (6PR)
8.00-16
R1 Agricultural - Rear
13.6-28
14.9-24
R3 Turf - Front
27X10.50-15
Not Published
R3 Turf - Rear
44X18.00-20 (4PR)
Not Published
R4 Industrial - Front
10-16.5 (6PR)
10.0-16.5
R4 Industrial - Rear
16.9-24 (6PR)
17.5L-R24
Quick Attach Loader System
400E loader: a dealer parking kit allows the loader to be attached and detached; without it the loader is fixed and cannot be detached; optional parking stands
Not Published
Loader Model
400E
320R
Loader Lift Height
400E: 112 in (to pivot pin)
H165: 103 in; 320R: 103 in
Loader Lift Capacity (Full Height)
400E: 2,391 lb (at pivot, full height)
320R: 1,393 lb (to maximum height at pivot pin)
Loader Breakout Force
400E: 3,853 lbf at pivot point; 2,902 lbf at 500 mm forward of pivot point
H165: 3,769 lbf; 320R: 3,769 lbf (at pivot point)
Warranty Length & Coverage
Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
3-year / 2,000-hour limited warranty (as sold new)
