▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 4TNV88C-MJT 3TNV84T-BMJT Engine Type Naturally-aspirated 4-cylinder Diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 4 3 Displacement 133.5 in³ 91.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 42.5 hp 37.2 hp PTO Power 33.6 hp 30.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dry type with safety element Fuel System High-pressure common rail direct injection Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator 75 A, 12 V 40 A ▶ HydraulicsPump Type Dual Independent Dual tandem gear pump Implement Flow 10.2 gpm 8.6 gpm Steering Flow 5.7 gpm 5.3 gpm Total Hydraulic Flow 15.9 gpm 13.9 gpm Overall Hydraulic Pump Flow 15.9 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3rd, 4th, and 5th optional Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 15 gal; Cab: 14.7 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity OOS: 6.8 qt; Cab: 8.0 qt 1.4 gal (open station); 1.8 gal (cab) Crankcase Capacity 5.6 qt (with filter) 5.1 qt Transmission / Hydraulic System Capacity 12.5 gal 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity 5.3 qt 1.2 gal ▶ PTO & HitchPTO Type Independent, 540 rpm (wet disc clutch) Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 3,130 lb 2,530 lb Hitch Lift Capacity (at 24”) 2,500 lb 2,200 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type eHydro (3-range hydrostatic) eHydro 3-range (4WD only); PowrReverser 12F/12R (4WD only) No. of Speeds Infinitely-variable, 3 range Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 18.6 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) 18.6 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch n/a Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Differential lock: standard, rear Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Folding ROPS; cab optional; MFWD standard Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Deluxe adjustable vinyl seat with arm rests and swivel; air seat suspension kit optional Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating (Continuous) 3,307 lb 1,587 to 3,197 lb Drawbar Capacity Max vertical load 1,103 lb Drawbar tongue capacity: 882 lb; maximum static vertical load: 562 lb ▶ Dimensions & ManeuverabilityOverall Width 78.2 in 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 73 in 68 in Ground Clearance Front axle: 15.6 in 12.2 in (rear axle) Min. Turn Radius without Brakes 17.1 ft Not Published Height to Top of ROPS 100.2 in 93.3 in Height to Top of ROPS (folded) 80.5 in Not Published Height to Top of Cab Model 97.4 in 89.4 in Overall Length 130.6 in (with 3-point hitch) 120.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,770 lb (operating weight) 2,900 lb (open station); 3,570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 8-16 (6PR) 7.00-14 R1 Agricultural - Rear 13.6-28 11.2-24 R3 Turf - Front 27X10.50-15 27x8.50-15 R3 Turf - Rear 44X18.00-20 (4PR) 41x14.00-20 R4 Industrial - Front 10-16.5 (6PR) 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear 16.9-24 (6PR) 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System 440R: Quik-Park loader system; 400E: optional parking kit John Deere Quik-Park Loader Model 440R or 440R MSL; 400E on open-station tractors 300CX; H160; H165; 300R; 320R Loader Lift Height 440R: 110 in; 400E: 112 in (to pivot pin) H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) 440R: 2,539 lb; 440R MSL: 2,213 lb; 400E: 2,391 lb (at pivot, full height) H160: 1,360 lb; H165: 1,598 lb; 300R: 1,360 lb; 320R: 1,598 lb (to maximum height at pivot pin) Loader Breakout Force 400E: 3,853 lbf at pivot point; 2,902 lbf at 500 mm forward of pivot point; 440R: 4,027 lbf at pivot point; 3,037 lbf at 500 mm forward of pivot pin H160: 2,855 lbf; H165: 3,327 lbf; 300R: 2,855 lbf; 320R: 3,327 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published
