▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 4TNV88C-MJT 3TNV86CT-KJPT Engine Type Naturally-aspirated 4-cylinder Diesel 4-cycle, inline, water-cooled diesel, turbocharged No. of Cylinders 4 3 Displacement 133.5 in³ 100.1 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 43.1 hp 41.6 hp PTO Power 34.6 hp 36.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dual element (dry type with safety element) Dual element Fuel System High-pressure common rail direct injection Direct injection Alternator 75 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Dual Independent Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 10.2 gpm 5.0 gpm Steering Flow 5.7 gpm 3.6 gpm Total Hydraulic Flow 15.9 gpm Not Published Overall Hydraulic Pump Flow 15.9 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 15.0 gal 10.0 gal Coolant Capacity 6.8 qt 1.3 gal Crankcase Capacity 5.6 qt (with filter) 1.1 gal Transmission / Hydraulic System Capacity 12.5 gal 9.2 gal Front Axle Fluid Capacity 5.3 qt 1.0 gal ▶ PTO & HitchPTO Type Independent (electrohydraulic) Transmission PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity 3,130 lb 2081.2 lb Hitch Lift Capacity (at 24”) 2,500 lb 2081.2 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser 8F/8R synchromesh shuttle shift gear transmission No. of Speeds 12F/12R 8F/8R Max Travel Speed (Forward) 18.6 mph 12.9 mph Max Travel Speed (Reverse) 18.6 mph 13.5 mph Clutch Wet disc (PowrReverser); not applicable on eHydro Single dry traction (mechanical) Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Air suspension seat with swivel Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard 4WD Front Axle Rating (Continuous) 3307 lb 1940 lb Drawbar Capacity Max vertical load 1103 lb 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 111.2 in Overall Width 78.2 in 57.3 in Wheelbase 73.0 in 62.6 in Ground Clearance Front axle: 13.8 in 13.0 in Min. Turn Radius without Brakes 17.1 ft (5.2 m) 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 100.2 in Not Published Height to Top of ROPS (folded) 69.5 in Not Published Height to Top of Cab Model 97.4 in Not Published ▶ WeightTractor Weight (Base) 3,770 lb 3166 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 8.00-16 (6PR) 7-14 R1 Agricultural - Rear 13.6-28 11.2-24 R3 Turf - Front 27X10.50-15 27X8.50-15 R3 Turf - Rear 44X18.00-20 (4PR) 41X14-20 R4 Industrial - Front 260/70D16.5 25X8.50-14 R4 Industrial - Rear 420/85D24 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Quick-change attachment carrier Loader Model H180 (NSL) or H180MSL D160 Loader Lift Height 110 in 84.0 in Loader Lift Capacity (Full Height) NSL: 2,539 lb; MSL: 2,213 lb (at pivot) 1186 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf 1704 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
