▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 4TNV86CT-MJT PowerTech 3029H Engine Type Turbocharged 4-cylinder Diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 127.6 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 51.5 hp 57 hp PTO Power 41.2 hp 38.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Two paper elements Fuel System High-pressure common rail direct injection Not Published Alternator 75 A, 12 V 40 A ▶ HydraulicsPump Type Dual Independent Not Published Implement Flow 10.2 gpm 11.4 gpm Steering Flow 5.7 gpm 6.8 gpm Total Hydraulic Flow 15.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 15.9 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) 2 ▶ Fluid CapacityFuel Tank Capacity 15.0 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity 6.8 qt 10 qt Crankcase Capacity 5.6 qt (with filter) 9 qt Transmission / Hydraulic System Capacity 12.5 gal 10.3 gal Front Axle Fluid Capacity 5.3 qt 4.8 qt ▶ PTO & HitchPTO Type Independent (electrohydraulic) OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 rpm 540 rpm (540E optional with PowrReverser) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category 1 Category 2, convertible to 1 Hitch Lift Capacity 3,130 lb Not Published Hitch Lift Capacity (at 24”) 2,500 lb 3,192 lb Lift Control Type Position control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) SyncShuttle (standard); PowrReverser (optional) No. of Speeds Infinitely-variable, 3 range 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 18.6 mph Not Published Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet disc (PowrReverser); not applicable on eHydro Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Power steering Brakes Wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Optional mechanical suspension seat; adjustable weight 52-275.6 lb (115-275 lb); fore/aft adjustment; flips forward Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard 2WD or MFWD Front Axle Rating (Continuous) 3307 lb Not Published Drawbar Capacity Max vertical load 1103 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 137.8 in Overall Width 78.2 in 57.3 in Wheelbase 73.0 in 80.7 in Ground Clearance Front axle: 13.8 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 17.1 ft (5.2 m) 138 in Height to Top of ROPS 100.2 in 96.4 in Height to Top of ROPS (folded) 69.5 in 77.1 in Height to Top of Cab Model Not Published 94.3 in ▶ WeightTractor Weight (Base) 3,770 lb 2WD: 4,524 lb; MFWD: 5,511 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,054 lb ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 8.00-16 (6PR) 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear 13.6-28 14.9-28 R3 Turf - Front 27X10.50-15 9.5-16 R3 Turf - Rear 44X18.00-20 (4PR) 21.5L-16.1 R4 Industrial - Front 260/70D16.5 12.5/80-18 R4 Industrial - Rear 420/85D24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) H240 (NSL or MSL) Loader Model D170 H240NSL Loader Lift Height 112.1 in 131 in Loader Lift Capacity (Full Height) 2,391 lb (at pivot, NSL) 3,671 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf 4,504 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Not Published
