▶ EngineEngine Manufacturer Yanmar LS Mtron Engine Model 4TNV86CT-MJT L3C19-T Engine Type Turbocharged 4-cylinder Diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 127.6 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 51.5 hp 52 hp PTO Power 41.2 hp 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dry Fuel System High-pressure common rail direct injection Common rail direct injection (CRDI) Alternator 75 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual Independent Gear pump, engine drive Implement Flow 10.2 gpm 8.2 gpm Steering Flow 5.7 gpm 4.1 gpm Total Hydraulic Flow 15.9 gpm 12.3 gpm Overall Hydraulic Pump Flow 15.9 gpm 12.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 3 Pair (2 Detent, 1 STD) No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) 3 Pair (2 Detent, 1 STD) ▶ Fluid CapacityFuel Tank Capacity 15.0 gal PCT: 10.6 gal; PCTC: 12.4 gal Coolant Capacity 6.8 qt 2.3 gal Crankcase Capacity 5.6 qt (with filter) 1.6 gal Transmission / Hydraulic System Capacity 12.5 gal 11.4 gal Front Axle Fluid Capacity 5.3 qt 2.2 gal ▶ PTO & HitchPTO Type Independent (electrohydraulic) Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional (2,000 rpm) Category, 3-Point Hitch Category 1 Category II Hitch Lift Capacity 3,130 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,500 lb 2,469 lb Lift Control Type Position control Position & Draft ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) Synchro shuttle / Power Clutch No. of Speeds Infinitely-variable, 3 range F16 x R16 Max Travel Speed (Forward) 18.6 mph Not Published Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet disc (PowrReverser); not applicable on eHydro Power clutch (hydraulic clutch valve and lever) Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Hydrostatic Power Steering Brakes Wet disc Wet, Multi-disc Seat Suspension & Adjustability Optional mechanical suspension seat; adjustable weight 52-275.6 lb (115-275 lb); fore/aft adjustment; flips forward Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard Mechanical front-wheel drive (4WD) Front Axle Rating (Continuous) 3307 lb Not Published Drawbar Capacity Max vertical load 1103 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 133 in Overall Width 78.2 in 62.5 in Wheelbase 73.0 in 73.2 in Ground Clearance Front axle: 13.8 in Not Published Min. Turn Radius without Brakes 17.1 ft (5.2 m) 10.3 ft (3.1 m) Height to Top of ROPS 100.2 in PCT: 95 in Height to Top of ROPS (folded) 69.5 in Not Published Height to Top of Cab Model Not Published PCTC: 90 in ▶ WeightTractor Weight (Base) 3,770 lb PCT: 3,869 lb; PCTC: 4,380 lb Weight with ROPS and Loader Not Published 4,649 lb Weight with Cab and Loader Not Published 5,160 lb ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8.00-16 (6PR) 9.5-16 R1 Agricultural - Rear 13.6-28 13.6-24 R3 Turf - Front 27X10.50-15 28x8.5-15 R3 Turf - Rear 44X18.00-20 (4PR) 41x14-20 R4 Industrial - Front 260/70D16.5 12-16.5 R4 Industrial - Rear 420/85D24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model D170 LL4106; LL4001 Loader Lift Height 112.1 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) 2,391 lb (at pivot, NSL) LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year limited powertrain warranty
