▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 4TNV86CT-MJT CD3029DLV50 Engine Type Turbocharged 4-cylinder Diesel 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 127.6 in³ 179 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 50.8 hp 53 hp PTO Power 42.2 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dry type with safety element Fuel System High-pressure common rail direct injection Direct injection, rotary injection pump, electric shutoff Alternator 75 A, 12 V 40 A ▶ HydraulicsPump Type Dual Independent Tandem gear pump Implement Flow 10.2 gpm 11.4 gpm Steering Flow 5.7 gpm 6.8 gpm Total Hydraulic Flow 15.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 15.9 gpm 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Not Published ▶ Fluid CapacityFuel Tank Capacity OOS: 15 gal; Cab: 14.7 gal 18 gal (open station); 22 gal (cab) Coolant Capacity OOS: 6.8 qt; Cab: 8.0 qt 10 qt Crankcase Capacity 5.6 qt (with filter) 9 qt Transmission / Hydraulic System Capacity 12.5 gal 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Front Axle Fluid Capacity 5.3 qt 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent, 540 rpm (wet disc clutch) Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch PTO Rear 540 rpm 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity 3,130 lb Not Published Hitch Lift Capacity (at 24”) 2,500 lb 3,374 lb Lift Control Type Position control Position and depth control, top link draft sensing ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser CollarShift standard; SyncShuttle optional; PowrReverser optional No. of Speeds 12F/12R 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 18.6 mph 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Max Travel Speed (Reverse) 18.6 mph 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Clutch Wet disk, PowrReverser Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Two-post ROPS; cab optional; two-wheel drive or MFWD Steering Power Hydrostatic power steering Brakes Wet disc Wet disk, self-equalizing, self-adjusting Seat Suspension & Adjustability Deluxe adjustable vinyl seat with armrests and swivel Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard Two-wheel drive or mechanical front wheel drive (MFWD) Front Axle Rating (Continuous) 3,307 lb 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Drawbar Capacity Max vertical load 1,103 lb 1,675 lb (maximum permissible static vertical load, drawbar fully extended) ▶ Dimensions & ManeuverabilityOverall Width 78.2 in 94.6 in (maximum) Wheelbase 73.0 in 80.7 in Ground Clearance Front axle: 15.6 in 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) Min. Turn Radius without Brakes 17.1 ft 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Height to Top of ROPS 100.2 in 88.7 in (extended) Height to Top of ROPS (folded) 80.5 in 76.7 in Height to Top of Cab Model 97.4 in 97 in Overall Length 130.6 in (with 3-point hitch) 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,770 lb (operating weight) 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 R1 Agricultural - Front 8-16 (6PR) 8.3-24 (MFWD) R1 Agricultural - Rear 13.6-28 13.6-28 R3 Turf - Front 27X10.50-15 Not Published R3 Turf - Rear 44X18.00-20 (4PR) Not Published R4 Industrial - Front 10-16.5 (6PR) Not Published R4 Industrial - Rear 16.9-24 (6PR) Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park easy-to-attach/detach loader Not Published Loader Model 440R or 440R MSL; 400E on open-station tractors 521; 541; 541 self-leveling; 542; 542 self-leveling Loader Lift Height 440R: 110 in; 400E: 112 in (to pivot pin) 521: 122 in; 541: 126 in; 541 self-leveling: 130 in Loader Lift Capacity (Full Height) 440R (H180): 2,539 lb; 440R MSL (H180MSL): 2,213 lb; 400E: 2,396 lb (at pivot, full height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) Loader Breakout Force 400E: 3,853 lbf at pivot; 2,902 lbf at 500 mm forward of pivot; 440R (non self-leveling): 4,027 lbf at pivot; 3,037 lbf at 500 mm forward of pivot 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
