▶ EngineEngine Manufacturer Yanmar FPT Engine Model 4TNV86CHT-MJT S8000 Engine Type Turbocharged 4-cylinder Diesel 3-cylinder, Tier 4 B/Final, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 127.6 in³ 178.8 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 65 hp 64 hp PTO Power 51.9 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Liquid-cooled Air Cleaner Dual element Not Published Fuel System High-pressure common rail direct injection Electronic high pressure common rail Alternator 75 A 120 A ▶ HydraulicsPump Type Dual Independent Fixed displacement Implement Flow 10.2 gpm 12.6 gpm Steering Flow 5.7 gpm Not Published Total Hydraulic Flow 15.9 gpm 12.6 gpm Overall Hydraulic Pump Flow 15.9 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 15.0 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity 5.6 qt Not Published Transmission / Hydraulic System Capacity 12.5 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, 540 rpm Independent PTO Rear 540 rpm 540 (standard); 540/540E (optional) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I/II Category I/II Hitch Lift Capacity 3,130 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 2,500 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type eHydro (3-range hydrostatic); no PowrReverser gear option offered MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds EHydro: infinitely variable, 3-range MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) 18.6 mph 18.6 mph Max Travel Speed (Reverse) 18.6 mph Not Published Clutch n/a MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) Differential Lock & Limited Slip Options Differential lock: Yes Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Mechanical contoured seat, adjustable; optional air-suspension seat Front Axle Type Mechanical front wheel drive (MFWD) - Standard 2WD or MFD with limited slip Front Axle Rating (Continuous) 3,307 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 71.3 in Not Published Wheelbase 73.0 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 2WD: 98 in; MFD: 100 in Overall Length 134.7 in (with 3-point hitch) 155.3 in ▶ WeightTractor Weight (Base) 4,255 lb (operating weight) 2WD Cab: 6,173 lb; MFD Cab: 6,834 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R4 Industrial R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front Not Published 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear Not Published 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 31.5x13-16.5 (10PR) Not Published R4 Industrial - Rear 16.9-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 440R Quik-Park loader; 440R Mechanical Self-Leveling (MSL) option L610 Loader Lift Height 440R: 110 in (to pivot pin) 120 in Loader Lift Capacity (Full Height) 440R: 2,539 lb (at pivot, full height) NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force 440R: 4,027 lbf at pivot; 3,037 lbf at 19.7 in ahead of pivot Not Published ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
