▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 4TNV86CHT-MJT Not Published Engine Type Turbocharged 4-cylinder Diesel Diesel, turbocharged No. of Cylinders 4 3 Displacement 127.6 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 65.9 hp 60 hp PTO Power 57 hp OOS: 45.6 hp; Cab: 42.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dry type with safety element Fuel System High-pressure common rail direct injection Electronically controlled, high-pressure common rail Alternator 75 A, 12 V OOS: 70 A; Cab: 110 A ▶ HydraulicsPump Type Dual Independent Tandem gear pump (implement + steering) Implement Flow 10.2 gpm 11.4 gpm Steering Flow 5.7 gpm 6.8 gpm Total Hydraulic Flow 15.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 15.9 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) 1 ▶ Fluid CapacityFuel Tank Capacity 15.0 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 6.8 qt Open operator station: 2.85 gal; Cab: 3.08 gal Crankcase Capacity 5.6 qt (with filter) 9.0 qt (with filter) Transmission / Hydraulic System Capacity 12.5 gal 8.36 gal (9x3); 9.46 gal (12x12) Front Axle Fluid Capacity 5.3 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent (electrohydraulic) Independent PTO Rear 540 rpm 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category 1 Category 2, convertible to 1 Hitch Lift Capacity 3,130 lb 3,968 lb Hitch Lift Capacity (at 24”) 2,500 lb 3,192 lb Lift Control Type Position control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) SyncShuttle (standard); PowrReverser (optional) No. of Speeds Infinitely-variable, 3 range 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 18.6 mph 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Max Travel Speed (Reverse) 18.6 mph 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Clutch Wet disc (PowrReverser); not applicable on eHydro Wet traction clutch (PowrReverser) Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Hydrostatic power steering Brakes Wet disc Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Optional mechanical suspension seat; adjustable weight 52-275.6 lb (115-275 lb); fore/aft adjustment; flips forward Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Front Axle Type Mechanical front wheel drive (MFWD) - Standard 2WD or MFWD Front Axle Rating (Continuous) 3307 lb Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Drawbar Capacity Max vertical load 1103 lb 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 143.3 in Overall Width 78.2 in Not Published Wheelbase 73.0 in 80.7 in Ground Clearance Front axle: 13.8 in Not Published Min. Turn Radius without Brakes 17.1 ft (5.2 m) 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 100.2 in Not Published Height to Top of ROPS (folded) 69.5 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,770 lb 5,445 to 6,702 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front 8.00-16 (6PR) 11L-15 R1 Agricultural - Rear 13.6-28 14.9-28 R3 Turf - Front 27X10.50-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear 44X18.00-20 (4PR) 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front 260/70D16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear 420/85D24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) 512 or 520M Loader Model D170 512 or 520M Loader Lift Height 112.1 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) 2,391 lb (at pivot, NSL) 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
