▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 4TNV86CHT-MJT V3307-CR-TE4 Engine Type Turbocharged 4-cylinder Diesel Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 127.6 in³ 203 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 65.9 hp 65.4 hp PTO Power 57 hp 52 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dual element (primary and secondary elements) Fuel System High-pressure common rail direct injection Common Rail System (CRS) Alternator 75 A, 12 V 130 A, 12 V ▶ HydraulicsPump Type Dual Independent Gear Implement Flow 10.2 gpm 16.7 gpm Steering Flow 5.7 gpm 6.3 gpm Total Hydraulic Flow 15.9 gpm 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 15.9 gpm 23.0 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (SCD / FD) No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Max. 3 ▶ Fluid CapacityFuel Tank Capacity 15.0 gal 23.8 gal Coolant Capacity 6.8 qt 10.6 qt Crankcase Capacity 5.6 qt (with filter) 12.7 qt Transmission / Hydraulic System Capacity 12.5 gal 12.4 gal Front Axle Fluid Capacity 5.3 qt 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Independent (electrohydraulic) Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540/540E rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category 1 I / II Hitch Lift Capacity 3,130 lb 4189 lb Hitch Lift Capacity (at 24”) 2,500 lb 3307 lb Lift Control Type Position control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) 12-speed electro-hydraulic shuttle (option: 18-speed with creep) No. of Speeds Infinitely-variable, 3 range F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 18.6 mph 24.9 mph Max Travel Speed (Reverse) 18.6 mph 24.7 mph Clutch Wet disc (PowrReverser); not applicable on eHydro Multiple wet disc Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Front limited slip differential; Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Ultra Grand Cab II Steering Power steering (hydrostatic) Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Optional mechanical suspension seat; adjustable weight 52-275.6 lb (115-275 lb); fore/aft adjustment; flips forward Deluxe mechanical suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air ride seat Front Axle Type Mechanical front wheel drive (MFWD) - Standard Bevel gear type (4WD) Front Axle Rating (Continuous) 3307 lb Not Published Drawbar Capacity Max vertical load 1103 lb 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 142 in Overall Width 78.2 in 75.6 in Wheelbase 73.0 in 84.1 in Ground Clearance Front axle: 13.8 in 18.1 in Min. Turn Radius without Brakes 17.1 ft (5.2 m) 11.8 ft Height to Top of ROPS 100.2 in Not Published Height to Top of ROPS (folded) 69.5 in Not Published Height to Top of Cab Model Not Published 101 in ▶ WeightTractor Weight (Base) 3,770 lb 6008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 8.00-16 (6PR) 320/70R24 R1 Agricultural - Rear 13.6-28 420/75R34 R3 Turf - Front 27X10.50-15 9.50-24 R3 Turf - Rear 44X18.00-20 (4PR) 18.4-26 R4 Industrial - Front 260/70D16.5 14-17.5 R4 Industrial - Rear 420/85D24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) LA1154A: 2-Lever Quick Coupler Loader Model D170 LA1154A Loader Lift Height 112.1 in LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) 2,391 lb (at pivot, NSL) LA1154A: Height position: 2674 lb; Power position: 2928 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf LA1154A: Height position: 4079 lbf; Power position: 5128 lbf ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
