▶ EngineEngine Manufacturer Yanmar Kubota Engine Model 4TNV86CHT-MJT V2403-CR-E4-GL5 Engine Type Turbocharged 4-cylinder Diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 127.6 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 65 hp 62 hp PTO Power 57 hp 53 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (dry type with safety element) Dry paper, dual element Fuel System High-pressure common rail direct injection Electronic Common Rail System (CRS) Alternator 75 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Dual Independent Tandem pump - gear type Implement Flow 10.2 gpm 9.4 gpm Steering Flow 5.7 gpm 4.7 gpm Total Hydraulic Flow 15.9 gpm 14.1 gpm Overall Hydraulic Pump Flow 15.9 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3/4/5 optional Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity OOS: 15 gal; Cab: 14.7 gal 13.5 gal Coolant Capacity OOS: 6.8 qt; Cab: 8.0 qt 8.7 qt Crankcase Capacity 5.7 qt 9.9 qt Transmission / Hydraulic System Capacity 12.5 gal 11.9 gal Front Axle Fluid Capacity 5.8 qt Not Published ▶ PTO & HitchPTO Type Independent 540 Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability No mid-PTO offered Optional Category, 3-Point Hitch Category I SAE Category I & II Hitch Lift Capacity 3,130 lb 3,858 lb Hitch Lift Capacity (at 24”) 2,500 lb 2,976 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3F/3R hydrostatic); Optional: 12F/12R PowrReverser Hydrostatic transmission No. of Speeds Infinitely-variable, 3 range 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 18.6 mph 16.8 mph Max Travel Speed (Reverse) 18.6 mph 15.2 mph Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability Deluxe adjustable vinyl seat with arm rests, swivel and retractable seat belt; Air Seat Suspension Kit optional (open station) Suspension seat with swivel function Front Axle Type Mechanical front wheel drive (MFWD) - Standard 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating (Continuous) 3,307 lb Not Published Drawbar Capacity Max vertical load 1,103 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 78.2 in 67.3 in Wheelbase 73 in 75.4 in Ground Clearance Front axle: 15.6 in 15.4 in Min. Turn Radius without Brakes 9.84 ft (3.0 m) 9.2 ft (with brake applied) Height to Top of ROPS 100.2 in 98.0 in Height to Top of ROPS (folded) 80.5 in Not Published Height to Top of Cab Model 97.4 in Not Applicable Overall Length 130.6 in (with 3-point hitch) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,770 lb (operating weight) 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 8-16 (6PR) 9.5-16 R1 Agricultural - Rear 13.6-28 14.9-26; 13.6-28 R3 Turf - Front 27X10.50-15 29X12.50-15 R3 Turf - Rear 44X18.00-20 (4PR) 44X18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 16.9-24 (6PR, R4 Industrial) 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 440R: Quik-Park loader; 400E: non Quik-Park loader 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model 440R or 440R MSL; 400E on open-station tractors LA1055 Loader Lift Height 440R: 110 in; 400E: 112 in (to pivot pin) 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb; 400E: 2,391 lb (at pivot, full height) 2,361 lb (at pivot pin) Loader Breakout Force 400E: 3,853 lbf at pivot point; 2,902 lbf 500 mm forward of pivot point; 440R NSL: 4,027 lbf at pivot point; 3,037 lbf 500 mm forward of pivot pin; 440R MSL: 3,844 lbf at pivot point; 3,346 lbf 500 mm forward of pivot pin 3,171 lbf ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
