▶ EngineEngine Manufacturer Yanmar Iseki Engine Model 4TNV86CHT-MJT Not Published Engine Type Turbocharged 4-cylinder Diesel 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 127.6 in³ Not Published Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 65.9 hp 65.7 hp PTO Power 58 hp 50 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dual element (dry type with safety element) Not Published Fuel System High-pressure common rail direct injection Not Published Alternator 75 A, 12 V Not Published ▶ HydraulicsPump Type Dual Independent Two gear-type pumps Implement Flow 10.2 gpm 12.6 gpm Steering Flow 5.7 gpm 7.1 gpm Total Hydraulic Flow 15.9 gpm 19.7 gpm (12.6 + 7.1, computed) Overall Hydraulic Pump Flow 15.9 gpm 19.7 gpm (12.6 + 7.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Not Published ▶ Fluid CapacityFuel Tank Capacity 15.0 gal 14.0 gal Coolant Capacity 6.8 qt Not Published Crankcase Capacity 5.6 qt (with filter) Not Published Transmission / Hydraulic System Capacity 12.5 gal Not Published Front Axle Fluid Capacity 5.3 qt Not Published ▶ PTO & HitchPTO Type Independent (electrohydraulic) Independent with SoftStart electronic modulation PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category 1 Category I & II Hitch Lift Capacity 3,130 lb 3,483 lb Hitch Lift Capacity (at 24”) 2,500 lb 3,483 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser 3-range Servo-HST with 2 stages (Hi and Lo), electronically controlled No. of Speeds 12F/12R Not Published Max Travel Speed (Forward) 18.6 mph Not Published Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Wet disc (PowrReverser); not applicable on eHydro Not Published Differential Lock & Limited Slip Options Differential lock: standard, rear, mechanical Not Published ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Air suspension seat with swivel Not Published Front Axle Type Mechanical front wheel drive (MFWD) - Standard Not Published Front Axle Rating (Continuous) 3307 lb Not Published Drawbar Capacity Max vertical load 1103 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 130.6 in 132.3 in Overall Width 78.2 in 70.1 in Wheelbase 73.0 in Not Published Ground Clearance Front axle: 13.8 in 14.0 in Min. Turn Radius without Brakes 17.1 ft (5.2 m) Not Published Height to Top of ROPS 100.2 in Not Published Height to Top of ROPS (folded) 69.5 in Not Published Height to Top of Cab Model 97.4 in 92.9 in ▶ WeightTractor Weight (Base) 3,770 lb 4,608 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 8.00-16 (6PR) Not Published R1 Agricultural - Rear 13.6-28 Not Published R3 Turf - Front 27X10.50-15 Not Published R3 Turf - Rear 44X18.00-20 (4PR) Not Published R4 Industrial - Front 260/70D16.5 Not Published R4 Industrial - Rear 420/85D24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Skid steer Loader Model H180 (NSL) or H180MSL FL2814 Loader Lift Height 110 in FL2814: 111 in Loader Lift Capacity (Full Height) NSL: 2,539 lb; MSL: 2,213 lb (at pivot) FL2814: 2,570 lb Loader Breakout Force At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Not Published
