▶ EngineEngine Manufacturer Yanmar FPT Industrial Engine Model 4TNV86CHT-MJT F5C Engine Type Turbocharged 4-cylinder Diesel 4-cylinder diesel, turbocharged No. of Cylinders 4 4 Displacement 127.6 in³ 207 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 74.3 hp 74 hp PTO Power 60 hp 65 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry Fuel System High pressure common-rail direct injection Common rail fuel injection Alternator 75 A, 12 V 120 A ▶ HydraulicsPump Type Dual Independent Open-center; dual pumps (implement + dedicated steering and services pump) Implement Flow 10.2 gpm 12.5 gpm Steering Flow 5.7 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 15.9 gpm 19.8 gpm (mechanical shuttle); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 15.9 gpm 19.8 gpm (mechanical shuttle); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 14.7 gal 23.8 gal Coolant Capacity 8.0 qt Not Published Crankcase Capacity 5.7 qt (with filter) Not Published Transmission / Hydraulic System Capacity 12.5 gal Not Published Front Axle Fluid Capacity 5.8 qt Not Published ▶ PTO & HitchPTO Type Independent (wet disc clutch); PTO brake for mid & rear PTO Fully independent PTO Rear 540 rpm 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category II / I Hitch Lift Capacity 3,130 lb Not Published Hitch Lift Capacity (at 24”) 2,500 lb 3,664 lb Lift Control Type Position control Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds Infinitely variable / 3 range 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 18.7 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) 18.7 mph 20.1 mph Clutch Wet disc (PowrReverser); not applicable on eHydro Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Differential lock: Yes Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Not Published Steering Power steering (hydrostatic) Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Air suspension with swivel seat Deluxe air suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seatbelt (cab) Front Axle Type Mechanical front wheel drive (MFWD) - Standard Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Front Axle Rating 3,307 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.4 in 151 in Overall Width 78.3 in Not Published Wheelbase 73.0 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance 13.8 in Not Published Min. Turn Radius without Brakes 126.0 in 134 in (2WD front axle) Height to Top of ROPS 104.3 in Not Published Height to Top of ROPS (folded) 80.0 in 76 to 78.9 in Height to Top of Cab Model 97.4 in 94.8 to 97.8 in ▶ WeightTractor Weight (Base) Not Published 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow Not Published R1 Agricultural - Front 8.00-16 (6PR) Not Published R1 Agricultural - Rear 13.6-28 Not Published R3 Turf - Front 27X10.5-15 or 27X12LL-15 Not Published R3 Turf - Rear 44X18-20 or 22.5LL-16.1 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 16.9LX24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-Park Loader System; Quik-Change Attachment Carrier Skid-steer-style or Euro-style quick attach faceplate Loader Model 440R Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height NSL: 110 in; MSL: 109 in (at pivot pin) 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb (at pivot pin, 4R Series figures) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force NSL: 4,027 lbf; MSL: 3,917 lbf (at pivot pin) 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Not Published
