▶ EngineEngine Manufacturer Yanmar Deutz Engine Model 4TNV86CHT-MJT TCD2.9 L4 Engine Type Turbocharged 4-cylinder Diesel Turbocharged No. of Cylinders 4 4 Displacement 127.6 in³ 177.0 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 74.3 hp 74 hp PTO Power 60 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System High pressure common-rail direct injection Common Rail Direct Injection Alternator 75 A, 12 V 95 A, 12 V ▶ HydraulicsPump Type Dual Independent Not Published Implement Flow 10.2 gpm 10.3 gpm Steering Flow 5.7 gpm 5.8 gpm Total Hydraulic Flow 15.9 gpm 16.1 gpm Overall Hydraulic Pump Flow 15.9 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Not Published ▶ Fluid CapacityFuel Tank Capacity 14.7 gal 23.8 gal Coolant Capacity 8.0 qt 10.6 qt Crankcase Capacity 5.7 qt (with filter) 8.5 qt Transmission / Hydraulic System Capacity 12.5 gal 18.0 gal Front Axle Fluid Capacity 5.8 qt 17.4 qt ▶ PTO & HitchPTO Type Independent (wet disc clutch); PTO brake for mid & rear PTO Independent PTO Rear 540 rpm 540/750 rpm Mid-PTO Availability No mid-PTO offered No mid-PTO offered Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 3,130 lb 5,115 lb Hitch Lift Capacity (at 24”) 2,500 lb 3,414 lb Lift Control Type Position control Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser RK74 Power Shuttle Cab (RK74PSC): 16F/16R Power Shuttle w/creeper; RK74 Shuttle Shift Cab: 16F/16R Syncro Shuttle w/creeper No. of Speeds Infinitely variable / 3 range 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) 18.7 mph 18.9 mph Max Travel Speed (Reverse) 18.7 mph Not Published Clutch Wet disc (PowrReverser); not applicable on eHydro Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Differential lock: Yes 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Steering Power steering (hydrostatic) Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Air suspension with swivel seat High-back suspension seat with extension Front Axle Type Mechanical front wheel drive (MFWD) - Standard Center-pivot, reverse Elliot type (4WD) Front Axle Rating 3,307 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.4 in 157.5 in Overall Width 78.3 in 76.4 in Wheelbase 73.0 in 86.1 in Ground Clearance 13.8 in 18.3 in Min. Turn Radius without Brakes 126.0 in 162.8 in Height to Top of ROPS 104.3 in Not Published Height to Top of ROPS (folded) 80.0 in Not Published Height to Top of Cab Model 97.4 in 103.3 in ▶ WeightTractor Weight (Base) Not Published 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front 8.00-16 (6PR) 11.2-24 R1 Agricultural - Rear 13.6-28 16.9-30 R3 Turf - Front 27X10.5-15 or 27X12LL-15 12.0-20.5 R3 Turf - Rear 44X18-20 or 22.5LL-16.1 22.4-25.5 R4 Industrial - Front 10-16.5 15-19.5 R4 Industrial - Rear 16.9LX24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick-Park Loader System; Quik-Change Attachment Carrier L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model 440R L135SL Loader Lift Height NSL: 110 in; MSL: 109 in (at pivot pin) L135SL: 135.5 in Loader Lift Capacity (Full Height) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb (at pivot pin, 4R Series figures) L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force NSL: 4,027 lbf; MSL: 3,917 lbf (at pivot pin) L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 2-year full machine warranty; 5-year, 3,000-hour powertrain warranty (no deductible, parts and labor)
