▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-KJT 3TNV86CHT-MJT Engine Type 3-cylinder turbocharged liquid-cooled diesel, direct injection Diesel No. of Cylinders 3 3 Displacement 91.5 in³ 97.6 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 41 hp 44.7 hp PTO Power 32.5 hp 36.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water pump Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff High pressure common rail direct injection (HPCR) Alternator 40 A 75 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Implement Flow 9.2 gpm 8.6 gpm Steering Flow 5.7 gpm 5.9 gpm Total Hydraulic Flow 14.8 gpm 14.4 gpm Overall Hydraulic Pump Flow 14.8 gpm 14.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Up to 6 rear remotes ▶ Fluid CapacityFuel Tank Capacity 11.5 gal Open station (OOS): 13.5 gal; Cab: 11.8 gal Coolant Capacity 1.4 gal Open station (OOS): 1.4 gal; Cab: 1.9 gal Crankcase Capacity 4.5 qt 1.5 gal Transmission / Hydraulic System Capacity 8.3 gal 6.8 gal Front Axle Fluid Capacity 1.2 gal 1.3 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2100 rpm) Category, 3-Point Hitch Category 1 Limited Category I Hitch Lift Capacity Not Published 2530 lb at hitch ball Hitch Lift Capacity (at 24”) 2200 lb 2,194 lb at 24 in behind link arms Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic 3-range hydrostatic (eHydro) No. of Speeds Infinite forward and reverse, 2 ranges Infinite / 3 range Max Travel Speed (Forward) 13 mph 18.50 mph Max Travel Speed (Reverse) 12.6 mph 18.50 mph Clutch Wet disk Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (ball, ramp and pin) Differential lock; Limited slip differential ▶ Chassis, Steering & ControlsFrame Type Fixed ROPS; four-wheel drive standard Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Scissor-link suspension seat; adjustable Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Mechanical front wheel drive (MFWD) Front Axle Rating 3197 lb 3196 lb Drawbar Capacity 882 lb 899 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 120.2 in Overall Width 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) 69.1 in Wheelbase 68 in 68.0 in Ground Clearance 14.7 in (front axle) 12.2 in Min. Turn Radius without Brakes Not Published 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 87.6 in 93.3 in Height to Top of ROPS (folded) Not Published 72.0 in Height to Top of Cab Model Not Published 85.0 in ▶ WeightTractor Weight (Base) 2899 lb 2900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-24 rear) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 8.00-16 7-14 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front 10.0-16.5 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear 17.5L-24 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quik-Park mounting system Loader Model 300CX H160 Loader Lift Height H165: 103 in; 320R: 103 in 90 in Loader Lift Capacity (Full Height) 300CX: 1393 lb (at full height, measured at pivot) 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot Loader Breakout Force H165: 3769 lbf; 320R: 3769 lbf; 300CX: 3769 lbf (at pivot point) 2,855 lb at pivot; 2,032 lb @ 19.7 in ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
