▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-KJT 3TNV84T-BMJT Engine Type 3-cylinder turbocharged liquid-cooled diesel, direct injection 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 91.5 in³ 91.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 41 hp 37.2 hp PTO Power 32.5 hp 30 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection, self bleeding, in-line fuel pump with electric shutoff Alternator 40 A 40 A ▶ HydraulicsPump Type Dual tandem gear pump Dual tandem gear pump Implement Flow 9.2 gpm 8.6 gpm Steering Flow 5.7 gpm 5.3 gpm Total Hydraulic Flow 14.8 gpm 13.9 gpm Overall Hydraulic Pump Flow 14.8 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity 1.4 gal 5.6 qt (open station); 7.4 qt (cab) Crankcase Capacity 4.5 qt 5.1 qt Transmission / Hydraulic System Capacity 8.3 gal 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity 1.2 gal 1.2 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2100 rpm Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2200 lb 2200 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds Infinite forward and reverse, 2 ranges Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 13 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) 12.6 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch Wet disk Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Mechanical rear differential lock (ball, ramp and pin) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Fixed ROPS; four-wheel drive standard Two-post folding ROPS; cab optional; MFWD standard Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating 3197 lb 1587 to 3197 lb Drawbar Capacity 882 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 120.2 in Overall Width 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 68 in 68 in Ground Clearance 14.7 in (front axle) 12.2 in (rear axle) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 87.6 in 93.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 89.4 in ▶ WeightTractor Weight (Base) 2899 lb 2900 lb (open station); 3570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-24 rear) R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 8.00-16 7.00-14 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front 10.0-16.5 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear 17.5L-24 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Loader Model 300CX 300X; 300CX; H160; H165; 300R; 320R Loader Lift Height H165: 103 in; 320R: 103 in 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) 300CX: 1393 lb (at full height, measured at pivot) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) Loader Breakout Force H165: 3769 lbf; 320R: 3769 lbf; 300CX: 3769 lbf (at pivot point) 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) Not Published
