▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-KJT 4TNV88C-MJT Engine Type 3-cylinder turbocharged liquid-cooled diesel, direct injection Naturally-aspirated 4-cylinder Diesel No. of Cylinders 3 4 Displacement 91.5 in³ 133.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 41 hp 43.1 hp PTO Power 32.5 hp 33.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dual element (dry type with safety element) Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff High-pressure common rail direct injection Alternator 40 A 75 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Dual Independent Implement Flow 9.2 gpm 10.2 gpm Steering Flow 5.7 gpm 5.7 gpm Total Hydraulic Flow 14.8 gpm 15.9 gpm Overall Hydraulic Pump Flow 14.8 gpm 15.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published 3rd, 4th, and 5th optional (up to 5 total) ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 15.0 gal Coolant Capacity 1.4 gal 6.8 qt Crankcase Capacity 4.5 qt 5.6 qt (with filter) Transmission / Hydraulic System Capacity 8.3 gal 12.5 gal Front Axle Fluid Capacity 1.2 gal 5.3 qt ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent (electrohydraulic) PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published 3,130 lb Hitch Lift Capacity (at 24”) 2200 lb 2,500 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Standard: eHydro (3-range hydrostatic); Optional: 12F/12R PowrReverser No. of Speeds Infinite forward and reverse, 2 ranges Infinitely-variable, 3 range Max Travel Speed (Forward) 13 mph 18.6 mph Max Travel Speed (Reverse) 12.6 mph 18.6 mph Clutch Wet disk Wet disc (PowrReverser); not applicable on eHydro Differential Lock & Limited Slip Options Mechanical rear differential lock (ball, ramp and pin) Differential lock: standard, rear, mechanical ▶ Chassis, Steering & ControlsFrame Type Fixed ROPS; four-wheel drive standard ROPS - Foldable Steering Hydrostatic power steering Power steering (hydrostatic) Brakes Wet disk Wet disc Seat Suspension & Adjustability Not Published Air suspension seat with swivel Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Mechanical front wheel drive (MFWD) - Standard Front Axle Rating 3197 lb (Continuous) 3307 lb Drawbar Capacity 882 lb Max vertical load 1103 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 130.6 in Overall Width 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) 78.2 in Wheelbase 68 in 73.0 in Ground Clearance 14.7 in (front axle) Front axle: 13.8 in Min. Turn Radius without Brakes Not Published 17.1 ft (5.2 m) Height to Top of ROPS 87.6 in 100.2 in Height to Top of ROPS (folded) Not Published 69.5 in Height to Top of Cab Model Not Published 97.4 in ▶ WeightTractor Weight (Base) 2899 lb 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-24 rear) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 8.00-16 8.00-16 (6PR) R1 Agricultural - Rear 14.9-24 13.6-28 R3 Turf - Front Not Published 27X10.50-15 R3 Turf - Rear Not Published 44X18.00-20 (4PR) R4 Industrial - Front 10.0-16.5 260/70D16.5 R4 Industrial - Rear 17.5L-24 420/85D24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Model 300CX H180 (NSL) or H180MSL Loader Lift Height H165: 103 in; 320R: 103 in 110 in Loader Lift Capacity (Full Height) 300CX: 1393 lb (at full height, measured at pivot) NSL: 2,539 lb; MSL: 2,213 lb (at pivot) Loader Breakout Force H165: 3769 lbf; 320R: 3769 lbf; 300CX: 3769 lbf (at pivot point) At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
