▶ EngineEngine Manufacturer Yanmar Mahindra Engine Model 3TNV84T-KJT MDI 2700 R2 Engine Type 3-cylinder turbocharged liquid-cooled diesel, direct injection Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 3 4 Displacement 91.5 in³ 166.7 in³ Rated Engine Speed 2800 rpm 2300 rpm Engine Power (Gross) 41 hp 41 hp PTO Power 32.5 hp 31 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry type with safety cartridge and dust unloader valve Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection Alternator 40 A 45 A, 12 V ▶ HydraulicsPump Type Dual tandem gear pump Not Published Implement Flow 9.2 gpm 8.7 gpm Steering Flow 5.7 gpm 5.8 gpm Total Hydraulic Flow 14.8 gpm Not Published Overall Hydraulic Pump Flow 14.8 gpm Not Published Hydraulic System Type Open center Open center, full-live hydraulic with position and draft controls Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 None standard (1 spool optional) No. of Optional Remote Valves Not Published 1 spool ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 14.55 gal Coolant Capacity 1.4 gal 2.25 gal Crankcase Capacity 4.5 qt 2.14 gal Transmission / Hydraulic System Capacity 8.3 gal 10.57 gal Front Axle Fluid Capacity 1.2 gal 2.24 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch Live PTO Rear 540 rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity Not Published 3527 lb Hitch Lift Capacity (at 24”) 2200 lb Not Published Lift Control Type Position control Position & draft control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Full constant mesh No. of Speeds Infinite forward and reverse, 2 ranges 8F / 2R Max Travel Speed (Forward) 13 mph 17.6 mph Max Travel Speed (Reverse) 12.6 mph 7.53 mph Clutch Wet disk Dual Differential Lock & Limited Slip Options Mechanical rear differential lock (ball, ramp and pin) Foot-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Fixed ROPS; four-wheel drive standard Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk Fully enclosed dry disc Seat Suspension & Adjustability Not Published mComfort mechanical suspension seat Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Not Published Front Axle Rating 3197 lb Not Published Drawbar Capacity 882 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 128.9 in Overall Width 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) 82.6 in Wheelbase 68 in 76.7 in Ground Clearance 14.7 in (front axle) 8.7 in Min. Turn Radius without Brakes Not Published 147.63 in Height to Top of ROPS 87.6 in 92.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2899 lb 5192 lb Weight with ROPS and Loader Not Published 6746 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-24 rear) R4 Industrial (standard); R1 Agricultural (optional) R1 Agricultural - Front 8.00-16 9.5X16 R1 Agricultural - Rear 14.9-24 12.4X28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.0-16.5 12X16.5 R4 Industrial - Rear 17.5L-24 16.9X24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style quick-attach coupler Loader Model 300CX 4550-4L Loader Lift Height H165: 103 in; 320R: 103 in 4550-4L: 116.6 in Loader Lift Capacity (Full Height) 300CX: 1393 lb (at full height, measured at pivot) 4550-4L: 2,866 lb at pivot pins to full height Loader Breakout Force H165: 3769 lbf; 320R: 3769 lbf; 300CX: 3769 lbf (at pivot point) 4550-4L: 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) 7-Year Limited Powertrain Warranty
