▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV84T-KJT 4TNV88C-XKITL Engine Type 3-cylinder turbocharged liquid-cooled diesel, direct injection 4-cylinder, liquid-cooled diesel No. of Cylinders 3 4 Displacement 91.5 in³ 133.6 in³ Rated Engine Speed 2800 rpm Not Published Engine Power (Gross) 41 hp 41.4 hp PTO Power 32.5 hp 31 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry type with safety element Dual air cleaner element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Dual tandem gear pump Not Published Implement Flow 9.2 gpm 9.3 gpm Steering Flow 5.7 gpm 5.3 gpm Total Hydraulic Flow 14.8 gpm 14.6 gpm Overall Hydraulic Pump Flow 14.8 gpm 14.6 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 11.5 gal 13.2 gal Coolant Capacity 1.4 gal 6.3 qt Crankcase Capacity 4.5 qt 5.1 qt Transmission / Hydraulic System Capacity 8.3 gal 9.0 gal Front Axle Fluid Capacity 1.2 gal 2.4 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch Independent PTO Rear 540 rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 Category I & II Hitch Lift Capacity Not Published 3,190 lb Hitch Lift Capacity (at 24”) 2200 lb 2,750 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic Synchronized shuttle shift No. of Speeds Infinite forward and reverse, 2 ranges F8-R8 Max Travel Speed (Forward) 13 mph 17.7 mph Max Travel Speed (Reverse) 12.6 mph Not Published Clutch Wet disk Dry Single Differential Lock & Limited Slip Options Mechanical rear differential lock (ball, ramp and pin) Differential lock (foot pedal) ▶ Chassis, Steering & ControlsFrame Type Fixed ROPS; four-wheel drive standard Not Published Steering Hydrostatic power steering Power steering Brakes Wet disk Not Published Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges Selectable 2WD/4WD engagement Front Axle Rating 3197 lb Not Published Drawbar Capacity 882 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 120.2 in 133.6 in (with 3PH and R4 tires) Overall Width 63 in (minimum, R1 rear tires); 65.8 in (maximum, R4 rear tires) 70.9 in (with R4 tires) Wheelbase 68 in 74.8 in Ground Clearance 14.7 in (front axle) 15.5 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS 87.6 in 98.0 in (with R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2899 lb 3,916 lb Weight with ROPS and Loader Not Published 5,129 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 bar tread (8.00-16 front, 14.9-24 rear) or R4 industrial (10.0-16.5 front, 17.5L-24 rear) R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8.00-16 8.0 - 16.0 R1 Agricultural - Rear 14.9-24 14.9 - 24.0 R3 Turf - Front Not Published 27.0 - 10.5 R3 Turf - Rear Not Published 44 x 18 - 20.0 R4 Industrial - Front 10.0-16.5 10.0 - 16.5 R4 Industrial - Rear 17.5L-24 17.5L - 24.0 ▶ Loader & AttachmentsQuick Attach Loader System Not Published YL605: Skid steer quick attach Loader Model 300CX YL605 Loader Lift Height H165: 103 in; 320R: 103 in YL605: 113.0 in Loader Lift Capacity (Full Height) 300CX: 1393 lb (at full height, measured at pivot) YL605: 2,500 lb Loader Breakout Force H165: 3769 lbf; 320R: 3769 lbf; 300CX: 3769 lbf (at pivot point) YL605: 3,047 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) 10-year limited powertrain warranty or 3,000 hours (whichever comes first)
