▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNE84 3TNV86CT-NJT2 Engine Type 3-cylinder liquid-cooled diesel, direct injection Diesel No. of Cylinders 3 3 Displacement 91.3 in³ 95.7 in³ Rated Engine Speed 2700 rpm 2500 rpm Engine Power (Gross) 32.2 hp 36.7 hp PTO Power 27 hp 30 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water pump Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self-bleeding in-line fuel pump, electric shutoff Not Published Alternator 40 A 55 A, 12 V ▶ HydraulicsPump Type Dual gear pump Tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 8.3 gpm 5.3 gpm Steering Flow 5.0 gpm 4.0 gpm Total Hydraulic Flow 13.3 gpm 9.3 gpm Overall Hydraulic Pump Flow 13.3 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 7.5 gal Coolant Capacity 6.1 qt 5.5 qt Crankcase Capacity 4.5 qt 4.5 qt Transmission / Hydraulic System Capacity 6.3 gal (gear); 6.9 gal (hydrostatic) 22 qt Front Axle Fluid Capacity 4.7 qt 4 qt ▶ PTO & HitchPTO Type Independent, wet disk clutch and brake Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available, 2100 rpm Not available Category, 3-Point Hitch Category 1 Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,200 lb 1,356 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) Hydrostatic transmission (HST) No. of Speeds 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) Not Published Max Travel Speed (Forward) 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) Not Published Max Travel Speed (Reverse) 7.7 mph (SyncShift); 15.5 mph (hydrostatic) Not Published Clutch 1 multi-disk wet clutch, 4.88 in (SyncShift); 2 multi-disk wet clutches, 4.88 in (SyncReverser) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Standard ROPS or folding ROPS; 2WD or MFWD Not Published Steering Power steering, cylinder-assisted Power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD standard; MFWD optional, all ranges Not Published Front Axle Rating 1,588 to 3,197 lb 1,760 lb Drawbar Capacity 562 lb 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 50.0 in (minimum); 66.7 in (maximum) 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 68.0 in 62.8 in Ground Clearance 13.4 in (rear axle) 12.7 in (R4 tires) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 84.0 in (standard ROPS); 90.0 in (folding ROPS) 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 117 in (with 3-point hitch) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,600 lb (2WD); 2,900 lb (MFWD) 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) 7-14 R1 Agricultural - Rear 11.2-24 or 12.4-24 11.2-24 R3 Turf - Front 27x8.50-15 (2WD); 7.00-14 (MFWD) 27X8.50-15 R3 Turf - Rear 41x14.00-20 or 11.2-24 41X14-20 R4 Industrial - Front 25x8.50-14 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 15.00-19.5 15.00-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model 420; 430 300E Loader Lift Height 420: 87.6 in; 430: 101.4 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) 420: 1,195 lb; 430: 1,258 lb (to max height at pivot point) 1,186 lb (at pivot pin) Loader Breakout Force 420: 2,693 lbf; 430: 3,299 lbf (at pivot point) 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
