▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNE84 3TNV88-BMJT Engine Type 3-cylinder liquid-cooled diesel, direct injection 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 91.3 in³ 100.1 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 32.2 hp 32.4 hp PTO Power 27 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Fuel System Direct injection, self bleeding, in-line fuel pump with electric shutoff Direct injection, self bleeding, in-line fuel pump with electric shutoff Alternator 40 A 40 A ▶ HydraulicsPump Type Dual gear pump Dual tandem gear pump Implement Flow 8.3 gpm 8.6 gpm Steering Flow 5.0 gpm 5.3 gpm Total Hydraulic Flow 13.3 gpm 13.9 gpm Overall Hydraulic Pump Flow 13.3 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity 6.1 qt 5.6 qt (open station); 7.4 qt (cab) Crankcase Capacity 4.5 qt 5.1 qt Transmission / Hydraulic System Capacity 6.3 gal (gear); 6.8 gal (hydrostatic) 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity 4.7 qt 1.2 gal ▶ PTO & HitchPTO Type Independent, wet disk clutch and brake Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available, 2100 rpm Optional, 2100 rpm Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2200 lb 2200 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) 7.7 mph (SyncShift); 15.5 mph (hydrostatic) 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch One multi-disk wet clutch, 4.88 in (SyncShift); two multi-disk wet clutches, 4.88 in (SyncReverser) Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post fixed ROPS standard, folding ROPS optional; two- or four-wheel drive Two-post folding ROPS; cab optional; MFWD standard Steering Power steering, cylinder-assisted Hydrostatic power steering Brakes Wet disk Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD standard; mechanical front wheel drive (MFWD) optional, all ranges Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating 1588 to 3197 lb 1587 to 3197 lb Drawbar Capacity 562 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 117 in 120.2 in Overall Width 50.0 in (minimum); 66.7 in (maximum) 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 68.0 in 68 in Ground Clearance 13.4 in (rear axle) Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 84.0 in (standard ROPS); 90.0 in (folding ROPS) 93.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 89.4 in ▶ WeightTractor Weight (Base) 2600 lb (2WD); 2900 lb (MFWD) 2900 lb (open station); 3570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) 7.00-14 R1 Agricultural - Rear 11.2-24 or 12.4-24 11.2-24 R3 Turf - Front 27x8.50-15 (2WD); 7.00-14 (MFWD) 27x8.50-15 R3 Turf - Rear 41x14.00-20 or 11.2-24 41x14.00-20 R4 Industrial - Front 25x8.50-14 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear 15.00-19.5 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Loader Model 420; 430 300X; 300CX; H160; H165; 300R; 320R Loader Lift Height 420: 87.6 in; 430: 101.4 in 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) 420: 1195 lb; 430: 1258 lb (to max height at pivot point) 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) Loader Breakout Force 420: 2693 lbf; 430: 3299 lbf (at pivot point) 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
