John Deere 4320 vs Bad Boy Tractors 5045 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Folding ROPS; ComfortGard cab optional; four-wheel drive standard
Compact utility tractor, 4WD
Steering
Power steering
Hydrostatic power steering
Brakes
Wet disk
Wet, multi-disc
Seat Suspension & Adjustability
Air ride seat optional
Deluxe suspension seat
Front Axle Type
Mechanical front wheel drive (MFWD), standard, all ranges
Selectable 4WD
Front Axle Rating
3528 lb
Not Published
Drawbar Capacity
1103 lb
Not Published
Overall Length with 3-Point Hitch
128.2 in
127.4 in
Overall Width
65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires)
64.9 in
Wheelbase
71.5 in
71.1 in
Ground Clearance
Not Published
15.5 in
Min. Turn Radius without Brakes
Not Published
110.2 in (with brake applied)
Height to Top of ROPS
97.2 in
98.4 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
92.4 in
97.0 in
Tractor Weight (Base)
3700 lb (open station); 4345 lb (cab)
3,754 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear
