12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range
Max Travel Speed (Forward)
17.3 mph (PowrReverser); 16.9 mph (eHydro)
Not Published
Max Travel Speed (Reverse)
17.3 mph (PowrReverser); 16.9 mph (eHydro)
Not Published
Clutch
Multiple stage wet disk, 5.1 in (PowrReverser)
Multiple stage wet type
Differential Lock & Limited Slip Options
Mechanical rear differential lock
Mechanical engagement via right side heel pedal
Frame Type
Folding ROPS; ComfortGard cab optional; four-wheel drive standard
Not Published
Steering
Power steering
Power steering
Brakes
Wet disk
Internal wet disc brakes, independent foot pedals
Seat Suspension & Adjustability
Air ride seat optional
Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering
Front Axle Type
Mechanical front wheel drive (MFWD), standard, all ranges
Cast-steel 4WD front axle, center driveline, bevel-gear final drives
Front Axle Rating
3,528 lb
Not Published
Drawbar Capacity
1,103 lb
Not Published
Overall Width
65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires)
12x12 Power Shuttle: 71.1 in; HST: 65.4 in
Wheelbase
71.5 in
12x12 Power Shuttle: 80.3 in; HST: 77.9 in
Ground Clearance
Not Published
14.8 in
Min. Turn Radius without Brakes
Not Published
Not Published
Height to Top of ROPS
97.2 in
12x12 Power Shuttle: 103.2 in; HST: 102.4 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
92.4 in
12x12 Power Shuttle: 93.3 in; HST: 92.9 in
Overall Length
128.2 in (with 3-point hitch)
HST: 132.3 in
Tractor Weight (Base)
3,700 lb (open station); 4,345 lb (cab)
12x12 Power Shuttle: 4,233 lb (ROPS base weight)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear
AG, Turf, Industrial, Snow
R1 Agricultural - Front
8.00-16
9.5x16
R1 Agricultural - Rear
13.6-28
16.9x26
R3 Turf - Front
27x10.5-15
27x10.50-15
R3 Turf - Rear
44x18.00-20
44x18.00-20
R4 Industrial - Front
10.00-16.5
12-16.5
R4 Industrial - Rear
17.5L-24
18.4-24
Quick Attach Loader System
Not Published
DL135: Skid steer quick attach
Loader Model
440R (NSL and MSL)
DL135
Loader Lift Height
440R NSL: 109 in; 440R MSL: 109 in
DL135: 111 in (at pivot pin)
Loader Lift Capacity (Full Height)
440R NSL: 2,486 lb; 440R MSL: 2,477 lb (to maximum height at pivot pin)
