▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 4024T R753 Engine Type 4-cylinder, turbocharged, direct injection diesel Turbocharged 3-cylinder diesel No. of Cylinders 4 3 Displacement 149 in³ 136 in³ Rated Engine Speed 2400 rpm 2600 rpm Engine Power (Gross) 60 hp 60 hp PTO Power PowrReverser: 52 hp; eHydro: 50 hp 51 hp Engine Emissions Constraints Not Published Tier 4B Final Cooling System Type Liquid-cooled Not Published Air Cleaner Dry type with safety element 2-stage Fuel System Direct injection, mechanical fuel pump Direct injection / Common rail Alternator 70 A 75 A ▶ HydraulicsPump Type Dual tandem gear pump Dual hydraulic pumps; open center, fixed displacement gear pump Implement Flow 12 gpm 12 gpm Steering Flow 5.1 gpm 5.5 gpm Total Hydraulic Flow 17.1 gpm 17.5 gpm Overall Hydraulic Pump Flow 17.1 gpm 17.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal (open station); 13.8 gal (cab) 17.2 gal Coolant Capacity 1.6 gal (open station); 2.2 gal (cab) Not Published Crankcase Capacity 7.9 qt Not Published Transmission / Hydraulic System Capacity 10.3 gal (PowrReverser); 9.6 gal (eHydro) Not Published Front Axle Fluid Capacity 1.3 gal Not Published ▶ PTO & HitchPTO Type Independent, wet disk clutch and brake Independent PTO Rear 540 rpm 540 rpm (540E optional) Mid-PTO Availability Optional, 2100 rpm Not Published Category, 3-Point Hitch Category 1 Category II/I Hitch Lift Capacity 3,130 lb Not Published Hitch Lift Capacity (at 24”) 2,500 lb 2,701 lb Lift Control Type Position control Position control with mechanical draft control ▶ Transmission & DrivetrainTransmission Type PowrReverser 12F/12R standard; eHydro optional (4WD) 8x8 synchronized shuttle No. of Speeds 12 forward, 12 reverse (PowrReverser); infinite forward and reverse, 3 ranges (eHydro) 8F/8R Max Travel Speed (Forward) 17.3 mph (PowrReverser); 16.9 mph (eHydro) Not Published Max Travel Speed (Reverse) 17.3 mph (PowrReverser); 16.9 mph (eHydro) Not Published Clutch Multiple stage wet disk, 5.1 in (PowrReverser) Dry, 11 in diameter, organic plate Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock ▶ Chassis, Steering & ControlsFrame Type Folding ROPS; ComfortGard cab optional; four-wheel drive standard Not Published Steering Power steering Not Published Brakes Wet disk Individual mechanically actuated wet disc Seat Suspension & Adjustability Air ride seat optional Deluxe contoured suspension seat, adjusts to operator height Front Axle Type Mechanical front wheel drive (MFWD), standard, all ranges 4WD: limited-slip front axle with front differential lock, mechanical engagement Front Axle Rating 3,528 lb Not Published Drawbar Capacity 1,103 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires) 67.5 in (shipping width) Wheelbase 71.5 in ROPS 4WD: 77.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.2 in ROPS 4WD: 97.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.4 in Not Applicable Overall Length 128.2 in (with 3-point hitch) ROPS 4WD: 134 in ▶ WeightTractor Weight (Base) 3,700 lb (open station); 4,345 lb (cab) ROPS 2WD: 4,442 lb (shipping weight); ROPS 4WD: 5,059 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ Tire OptionsTire Size & Options R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear R1 agricultural, R3 turf, R4 industrial R1 Agricultural - Front 8.00-16 Not Published R1 Agricultural - Rear 13.6-28 14.9x28 R1 R3 Turf - Front 27x10.5-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10.00-16.5 Not Published R4 Industrial - Rear 17.5L-24 18.4x24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Loader Model 440R (NSL and MSL) 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) Loader Lift Height 440R NSL: 109 in; 440R MSL: 109 in 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in Loader Lift Capacity (Full Height) 440R NSL: 2,486 lb; 440R MSL: 2,477 lb (to maximum height at pivot pin) Not Published Loader Breakout Force 440R NSL: 3,934 lbf; 440R MSL: 3,917 lbf (at pivot point) 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in in front of pivot pin) ▶ WarrantyWarranty Length & Coverage 3-year / 2,000-hour limited warranty (as sold new) Not Published
