▶ EngineEngine Manufacturer John Deere LS Mtron Engine Model PowerTech 3029 (2.9L) EWR Not Published Engine Type Diesel, turbocharged Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 179 in³ 115.9 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 38 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Not Published Air Cleaner Dry type with safety element Not Published Fuel System Electronically controlled, high-pressure common rail Common rail direct injection Alternator 70 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Implement Flow 11.4 gpm 8.2 gpm Steering Flow 6.8 gpm Not Published Total Hydraulic Flow 18.2 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 18.2 gpm Not Published Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 19 gal Non-cab: 10.5 gal; Cab: 12.4 gal Coolant Capacity Not Published Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub Not Published ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category II, convertible to I Category I Hitch Lift Capacity 3,968 lb Not Published Hitch Lift Capacity (at 24”) 3,192 lb 2,756 lb Lift Control Type Position control, draft control, adjustable rate of drop Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type SyncShuttle 3-range hydrostatic (HST) No. of Speeds 9F/3R Infinitely variable, 3 ranges Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Not Applicable Differential Lock & Limited Slip Options Mechanical, rear Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Not Published Seat Suspension & Adjustability Deluxe adjustable vinyl seat with retractable seat belt Adjustable suspension seat Front Axle Type 2WD or MFWD Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase 80.7 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) Not Published Height to Top of ROPS Not Published 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published Not Applicable Overall Length 144.5 in 128.1 in ▶ WeightTractor Weight (Base) 5,335 to 5,809 lb (shipping weight) Non-cab: 3,770 lb; Cab: 4,453 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front MFWD: 9.5-24; 11.2-24; 12.4-24 Not Published R1 Agricultural - Rear 14.9-28 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Quick-Attach faceplate Loader Model 500E, 500M or 520M L360A Loader Lift Height 500M: 124 in 112 in Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 1,830 lb at 31.5 in. forward of pivot pin (L360A) Loader Breakout Force 500M: 4,354 lb (at pivot) 3,114 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years; powertrain 4 additional years
