▶ EngineEngine Manufacturer John Deere Yanmar Engine Model PowerTech 3029 (2.9L) EWR 4TNV86CT-MJT Engine Type Diesel, turbocharged Turbocharged 4-cylinder Diesel No. of Cylinders 3 4 Displacement 179 in³ 127.6 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 50 hp 50.8 hp PTO Power 38 hp 40.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Liquid Air Cleaner Dry type with safety element Dual element Fuel System Electronically controlled, high-pressure common rail High-pressure common rail direct injection Alternator 70 A 75 A ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Dual Independent Implement Flow 11.4 gpm 10.2 gpm Steering Flow 6.8 gpm 5.7 gpm Total Hydraulic Flow 18.2 gpm 15.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 15.9 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published None ▶ Fluid CapacityFuel Tank Capacity 19 gal 15.0 gal Coolant Capacity Not Published Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Transmission / Hydraulic System Capacity Not Published 12.5 gal Front Axle Fluid Capacity MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub 5.3 qt ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent 540 PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II, convertible to I Category I/II Hitch Lift Capacity 3,968 lb 3,130 lb Hitch Lift Capacity (at 24”) 3,192 lb 2,500 lb Lift Control Type Position control, draft control, adjustable rate of drop Position control ▶ Transmission & DrivetrainTransmission Type SyncShuttle eHydro (3-range hydrostatic); no PowrReverser gear option offered No. of Speeds 9F/3R EHydro: infinitely variable, 3-range Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Dry Wet; wet clutch disk diameter 5.08 in Differential Lock & Limited Slip Options Mechanical, rear Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published ROPS - Foldable Steering Hydrostatic power steering Power Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Wet disc Seat Suspension & Adjustability Deluxe adjustable vinyl seat with retractable seat belt Not Published Front Axle Type 2WD or MFWD Mechanical front wheel drive (MFWD) - Standard Front Axle Rating Not Published (Continuous) 3,307 lb Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Max vertical load 1,103 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published 71.3 in Wheelbase 80.7 in 73 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 144.5 in 134.7 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,335 to 5,809 lb (shipping weight) 4,255 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R4 Industrial R1 Agricultural - Front MFWD: 9.5-24; 11.2-24; 12.4-24 Not Published R1 Agricultural - Rear 14.9-28 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 31.5x13-16.5 (10PR) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Not Published Loader Model 500E, 500M or 520M 440R Loader Lift Height 500M: 124 in 440R: 110 in (to pivot pin) Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 440R: 2,539 lb (at pivot, full height) Loader Breakout Force 500M: 4,354 lb (at pivot) 440R: 4,027 lbf at pivot; 3,037 lbf at 19.7 in ahead of pivot ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
