▶ EngineEngine Manufacturer John Deere KIOTI Engine Model PowerTech 3029 (2.9L) EWR 3F183T Engine Type Diesel, turbocharged 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel No. of Cylinders 3 3 Displacement 179 in³ 111.4 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 38 hp 41.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Water-cooled Air Cleaner Dry type with safety element Dry type element Fuel System Electronically controlled, high-pressure common rail Common Rail Diesel (CRDI) Alternator 70 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Gear Implement Flow 11.4 gpm Not Published Steering Flow 6.8 gpm Not Published Total Hydraulic Flow 18.2 gpm 16.5 gpm Overall Hydraulic Pump Flow 18.2 gpm 16.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 19 gal 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity 9.0 qt (with filter) 1.58 gal Transmission / Hydraulic System Capacity Not Published 14.53 gal Front Axle Fluid Capacity MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub 1.8 gal ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II, convertible to I Category I Hitch Lift Capacity 3,968 lb 3,538 lb Hitch Lift Capacity (at 24”) 3,192 lb 3,177 lb Lift Control Type Position control, draft control, adjustable rate of drop Position with Draft Control ▶ Transmission & DrivetrainTransmission Type SyncShuttle Synchro Shuttle No. of Speeds 9F/3R 24x24 Max Travel Speed (Forward) Not Published 15.71 mph Max Travel Speed (Reverse) Not Published 13.96 mph Clutch Dry Dry Type Single Stage Differential Lock & Limited Slip Options Mechanical, rear Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Wet Multi Disc Seat Suspension & Adjustability Deluxe adjustable vinyl seat with retractable seat belt Adjustable Air-Ride Seat Front Axle Type 2WD or MFWD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width Not Published 65.6 in Wheelbase 80.7 in 75.6 in Ground Clearance Not Published 13.8 in Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) 9.8 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in Overall Length 144.5 in 139.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,335 to 5,809 lb (shipping weight) 4,342 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Agricultural, Turf, Industrial R1 Agricultural - Front MFWD: 9.5-24; 11.2-24; 12.4-24 8-16 R1 Agricultural - Rear 14.9-28 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model 500E, 500M or 520M KL6010 Loader Lift Height 500M: 124 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force 500M: 4,354 lb (at pivot) KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
