▶ EngineEngine Manufacturer John Deere LS Mtron Engine Model PowerTech 3029 (2.9L) EWR L3CRV-T8 Engine Type Diesel, turbocharged 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 179 in³ 114.7 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 38 hp Gear: 42.5 hp; HST: 40 hp Engine Emissions Constraints Tier 4 Tier 4B (final) Cooling System Type Liquid cooled with overflow reservoir Liquid cooled Air Cleaner Dry type with safety element Replaceable primary and inner elements Fuel System Electronically controlled, high-pressure common rail Electronically controlled common rail direct injection Alternator 70 A ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Gear Implement Flow 11.4 gpm 8.2 gpm Steering Flow 6.8 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 18.2 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 18.2 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 19 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity Not Published 2.3 gal Crankcase Capacity 9.0 qt (with filter) 5.8 qt Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub 2.2 gal ▶ PTO & HitchPTO Type Independent, mechanical engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category II, convertible to I Category I Hitch Lift Capacity 3,968 lb 2,756 lb Hitch Lift Capacity (at 24”) 3,192 lb 2,116 lb Lift Control Type Position control, draft control, adjustable rate of drop Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type SyncShuttle Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 9F/3R Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) Not Published Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) Not Published Gear: 15.3 mph; HST: 11.37 mph Clutch Dry Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Mechanical, rear Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Wet multi-disc Seat Suspension & Adjustability Deluxe adjustable vinyl seat with retractable seat belt ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 2WD or MFWD Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published 69.1 in Wheelbase 80.7 in 73.2 in Ground Clearance Not Published 15 in Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS Not Published 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94 in Overall Length 144.5 in 128.1 in ▶ WeightTractor Weight (Base) 5,335 to 5,809 lb (shipping weight) ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front MFWD: 9.5-24; 11.2-24; 12.4-24 9.5-16 R1 Agricultural - Rear 14.9-28 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12x16.5 R4 Industrial - Rear Not Published 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Tool-free loader mount; optional skid-steer quick-attach plates Loader Model 500E, 500M or 520M 260TLA Loader Lift Height 500M: 124 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force 500M: 4,354 lb (at pivot) 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
