John Deere 5055E vs John Deere 4520 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires)
Wheelbase
80.7 in
71.5 in
Ground Clearance
2WD: 18.8 in; MFWD: 13.4 in
Not Published
Min. Turn Radius without Brakes
11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle)
Not Published
Height to Top of ROPS
96.4 in
97.2 in
Height to Top of ROPS (folded)
77.1 in
Not Published
Height to Top of Cab Model
94.3 in
92.4 in
Overall Length
137.8 in
128.2 in (with 3-point hitch)
Tractor Weight (Base)
2WD: 4,524 lb; MFWD: 5,511 lb
3,700 lb (open station); 4,345 lb (cab)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Not Published
R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear
R1 Agricultural - Front
MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial
8.00-16
R1 Agricultural - Rear
14.9-28
13.6-28
R3 Turf - Front
9.5-16
27x10.5-15
R3 Turf - Rear
21.5L-16.1; 22.5LL-16.1 (Turf Special)
44x18.00-20
R4 Industrial - Front
12.5/80-18
10.00-16.5
R4 Industrial - Rear
16.9-24
17.5L-24
Quick Attach Loader System
520M; H240 (NSL or MSL)
Not Published
Loader Model
H240NSL
440R (NSL and MSL)
Loader Lift Height
131 in
440R NSL: 109 in; 440R MSL: 109 in
Loader Lift Capacity (Full Height)
3,671 lb (H240NSL, at pivot)
440R NSL: 2,486 lb; 440R MSL: 2,477 lb (to maximum height at pivot pin)
