▶ EngineEngine Manufacturer John Deere Kubota Engine Model John Deere PowerTech 3029 V2403-CR-TE4 Engine Type Diesel, turbocharged, liquid-cooled 4-cylinder, turbocharged, common-rail diesel No. of Cylinders 3 4 Displacement 179 in³ 148.5 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 59 hp 58.7 hp PTO Power 41 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, pressurized radiator with recovery tank Air Cleaner Dry type, dual element (primary and secondary) Dry paper dual element, 8 in diameter, pre-cleaner standard Fuel System Not Published Common rail direct injection Alternator 40 A 45 A ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 11.4 gpm 10.6 gpm Steering Flow 6.8 gpm 6.1 gpm Total Hydraulic Flow 18.2 gpm 16.5 gpm Overall Hydraulic Pump Flow 18.2 gpm 16.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 (SCD) No. of Optional Remote Valves 2 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal 17.2 gal Coolant Capacity 10 qt 8.5 qt Crankcase Capacity 9 qt 7.6 qt Transmission / Hydraulic System Capacity 10.3 gal 50.7 qt Front Axle Fluid Capacity Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) ▶ PTO & HitchPTO Type Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) Hydraulic, independent PTO, self-modulating multi-plate wet clutch with brake PTO Rear 540 rpm (540E optional with PowrReverser) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category I and II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 3,192 lb 3,307 lb Lift Control Type Position control with top link draft sensing Position control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) 8F/8R Max Travel Speed (Forward) Not Published 18.2 mph Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Dry (SyncShuttle); wet (12F/12R PowrReverser) Multiple wet disc Differential Lock & Limited Slip Options Differential lock, standard; pedal-operated, mechanical Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes Mechanical wet disc Seat Suspension & Adjustability Not Published Fully adjustable suspension seat with retractable seat belt Front Axle Type 2WD or MFWD M5660SUH: adjustable tubular-steel 2WD axle; M5660SUHD: cast-iron bevel-pinion drive, 55-degree turning angle, 4WD Front Axle Rating Not Published 4,410 lb at 55.9 in tread spacing (M5660SUH); 5,290 lb at 55.9 in tread spacing (M5660SUHD) Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) 3,300 lb (maximum tongue weight) ▶ Dimensions & ManeuverabilityOverall Width 57.3 in 72.8 in Wheelbase 80.7 in 82 in (M5660SUH); 80.7 in (M5660SUHD) Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in 16.3 in Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) 11.1 ft (M5660SUH); 12.8 ft (M5660SUHD) Height to Top of ROPS 96.4 in 95.3 in Height to Top of ROPS (folded) 77.1 in Not Published Height to Top of Cab Model 94.3 in Not Published Overall Length 137.8 in 138.7 in (M5660SUH); 136 in (M5660SUHD) ▶ WeightTractor Weight (Base) 2WD: 4,524 lb; MFWD: 5,511 lb 4,189 lb (M5660SUH); 4,387 lb (M5660SUHD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 R1 Agricultural - Front MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial 9.5L-15 (M5660SUH); 9.5-22 (M5660SUHD) R1 Agricultural - Rear 14.9-28 14.9-28 R3 Turf - Front 9.5-16 29x12.50-15 R3 Turf - Rear 21.5L-16.1; 22.5LL-16.1 (Turf Special) 21.5L-16.1 R4 Industrial - Front 12.5/80-18 12.5/80-18 (M5660SUHD) R4 Industrial - Rear 16.9-24 16.9-24 (M5660SUHD) ▶ Loader & AttachmentsQuick Attach Loader System 520M; H240 (NSL or MSL) LA1154SU: 2-lever quick attach coupler standard Loader Model H240NSL LA1154SU Loader Lift Height 131 in LA1154SU: 130.9 in (height position); 115.7 in (power position) Loader Lift Capacity (Full Height) 3,671 lb (H240NSL, at pivot) LA1154SU: 2,469 lb (height position); 2,928 lb (power position) Loader Breakout Force 4,504 lb (H240NSL, at pivot) LA1154SU: 4,230 lbf (height position); 5,354 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage
