▶ EngineEngine Manufacturer John Deere KIOTI (Daedong) Engine Model 3029H 3F183T Engine Type Diesel, turbocharged KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 3 3 Displacement 179 in³ 111.4 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 60 hp 60 hp PTO Power OOS: 45.6 hp; Cab: 42.9 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry type element Fuel System Electronically controlled, high-pressure common rail Common Rail Direct Injection (CRDI) Alternator OOS: 70 A; Cab: 110 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Gear Implement Flow 11.4 gpm 9.6 gpm Steering Flow 6.8 gpm 8.2 gpm Total Hydraulic Flow 18.2 gpm 17.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 17.9 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal 14.8 gal Coolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal 2.0 gal Crankcase Capacity 9.0 qt (with filter) 1.58 gal Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) 11.89 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II, convertible to I Category I & II Hitch Lift Capacity 3,968 lb 3,538 lb Hitch Lift Capacity (at 24”) 3,192 lb 3,177 lb Lift Control Type Position control, draft control, adjustable rate of drop Position with Draft Control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) Hydrostatic No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 3 Range Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 18.26 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 18.26 mph Clutch Wet traction clutch (PowrReverser) Not Published Differential Lock & Limited Slip Options Mechanical, rear Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Wet Multi Disc Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Adjustable Seat Front Axle Type 2WD or MFWD Not Published Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 143.3 in 139.6 in Overall Width Not Published 65.7 in Wheelbase 80.7 in 75.6 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) 10.0 ft Height to Top of ROPS Not Published 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in ▶ WeightTractor Weight (Base) 5,445 to 6,702 lb NX6010H: 4,198 lb; NX6010HC: 4,529 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 11L-15 9.5-16 R1 Agricultural - Rear 14.9-28 16.9-24 R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) 29-12.5-15 R3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) 21.5L-16.1 R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 10-16.5 R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System 512 or 520M Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model 512 or 520M KL6010 Loader Lift Height 512: 113 in; 520M: 132 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) 512: 2,453 lb; 520M: 3,523 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force 512: 4,781 lb; 520M: 4,641 lb KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor
