▶ EngineEngine Manufacturer John Deere Mahindra Engine Model 3029H VNEF Engine Type Diesel, turbocharged Four-stroke, Turbocharged, Direct Injection, Water Cooled Diesel Engine No. of Cylinders 3 3 Displacement 179 in³ 161.7 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 60 hp 60 hp PTO Power OOS: 45.6 hp; Cab: 42.9 hp 46.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dual dry Fuel System Electronically controlled, high-pressure common rail Direct Injection (mCRD fuel-injected) Alternator OOS: 70 A; Cab: 110 A 90 A, 12 V ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Implement Flow 11.4 gpm 11.8 gpm Steering Flow 6.8 gpm 4.9 gpm Total Hydraulic Flow 18.2 gpm 16.7 gpm Overall Hydraulic Pump Flow 18.2 gpm 16.7 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 Spool No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal 16 gal Coolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal 9.0 qt Crankcase Capacity 9.0 qt (with filter) 7.1 qt Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) 9.2 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side 10.5 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm @ 2300 rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II, convertible to I CAT I with Telescoping Stabilizers & Flex Links Hitch Lift Capacity 3,968 lb 3314 lb Hitch Lift Capacity (at 24”) 3,192 lb 2945 lb Lift Control Type Position control, draft control, adjustable rate of drop Position Control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) HST No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Infinite / 3 Ranges Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 17.6 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 17.6 mph Clutch Wet traction clutch (PowrReverser) Damper Differential Lock & Limited Slip Options Mechanical, rear Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Wet Disc Brake, Mechanical Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment mComfort seat (mechanical suspension; adjustable headrest; foldable armrests) Front Axle Type 2WD or MFWD Not Published Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 143.3 in 138.8 in Overall Width Not Published 71.1 in Wheelbase 80.7 in 73.7 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) 155.5 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 102 in ▶ WeightTractor Weight (Base) 5,445 to 6,702 lb 4585 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 5855 lb ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural, R4 Industrial, R3 Turf R1 Agricultural - Front 11L-15 9.5X16 6PR R1 Agricultural - Rear 14.9-28 14.9X24 6PR R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) LSW305-521 R3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) LSW570-648 R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 12X16.5 6PR R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 16.9X24 8PR ▶ Loader & AttachmentsQuick Attach Loader System 512 or 520M 2660CL: Quick-attach adapter included (loader interfaces with compatible attachments via quick-attach system). Loader Model 512 or 520M 2660CL Loader Lift Height 512: 113 in; 520M: 132 in 2660CL: 115.4 in Loader Lift Capacity (Full Height) 512: 2,453 lb; 520M: 3,523 lb 2660CL: 3,122 lb at pivot pin to full height Loader Breakout Force 512: 4,781 lb; 520M: 4,641 lb 2660CL: 5,225 lb ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 7-Year Limited Powertrain Warranty
