▶ EngineEngine Manufacturer John Deere Daedong Engine Model John Deere PowerTech 3029 4HT-TP4A Engine Type Diesel, turbocharged, liquid-cooled Turbocharged diesel No. of Cylinders 3 4 Displacement 179 in³ 148.6 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 67 hp 66.4 hp PTO Power 48.3 hp 57.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Two paper elements Not Published Fuel System Not Published Common rail Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.4 gpm 11.0 gpm Steering Flow 6.8 gpm 6.9 gpm Total Hydraulic Flow 18.2 gpm 17.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 17.9 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 19.6 gal 22.5 gal Coolant Capacity 10 qt Not Published Crankcase Capacity 9 qt Not Published Transmission / Hydraulic System Capacity 2WD: 10 gal; 4WD: 10.3 gal Not Published Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type OOS: independent, mechanical actuation; Cab: independent, mechanical or electrohydraulic actuation Independent PTO Rear 540 rpm (540E optional with PowrReverser) 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,192 lb 3,594 lb Lift Control Type Position control with top link draft sensing Position with draft control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) 3-range powershuttle with electronic clutch No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) 12 forward, 12 reverse Max Travel Speed (Forward) Not Published 19.8 mph Max Travel Speed (Reverse) Not Published 19.5 mph Clutch Dry (SyncShuttle); dry or wet (12F/12R PowrReverser) Electronic clutch Differential Lock & Limited Slip Options Rear diff lock, standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering with tilt wheel Brakes Hydraulic wet disc brakes Wet multi-disc Seat Suspension & Adjustability Not Published Suspension seat, fully adjustable (standard) Front Axle Type 2WD or MFWD Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 137.8 in 148.8 in Overall Width 57.3 in 77.2 in Wheelbase 80.7 in 82.7 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in 12.3 in Min. Turn Radius without Brakes 138 in 147.0 in Height to Top of ROPS 98.4 in 102.1 in Height to Top of ROPS (folded) 78.5 in Not Published Height to Top of Cab Model 95.6 in Not Published ▶ WeightTractor Weight (Base) 2WD: 4,634 lb; MFWD: 5,621 lb 5,440 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Industrial (standard), Agricultural, Multi-Use R1 Agricultural - Front 2WD: 7.5-16; MFWD: 9.5-24 9.5-24 R1 Agricultural - Rear 16.9-28 16.9-30 R3 Turf - Front 9.5-16 (4WD) Not Published R3 Turf - Rear 21.5L-16.1; 22.5LL-16.1 (Turf Special) Not Published R4 Industrial - Front 12.5-80-18 (4WD) 12.5/80-18 R4 Industrial - Rear 16.9-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System H240 (NSL or MSL) Bob-Tach Loader Model H240NSL FL10 Loader Lift Height 131 in 129.3 in Loader Lift Capacity (Full Height) 3,671 lb 2,641 lb Loader Breakout Force 4,504 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours
