Tractor Comparison

Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.

2 of 4 selected

—

JohnDeere5065E

—

JohnDeere1023E

Comparison loaded for 2 tractors.

Spec	John Deere5065E	John Deere1023E


PTO Power	—	16.2 hp
Alternator	—	40 A
Air Cleaner	—	Dual element
Engine Type	—	Diesel
Fuel System	—	Indirect injection
Displacement	—	60.6 in³
No. of Cylinders	—	3
Rated Engine Speed	—	3200 rpm
Cooling System Type	—	Water pump
Engine Manufacturer	—	Yanmar
Engine Power (Gross)	—	21.5 hp @ 200 rpm
Engine Emissions Constraints	—	Tier 4

Tractor Weight (Base)	—	Open station: 1446 lb
Weight with ROPS and Loader	—	1446 lb

Warranty Length & Coverage	—	6-year powertrain warranty (as stated in 2016 review; current terms may vary)

Pump Type	—	Single gear
Steering Flow	—	3.5 gpm
Implement Flow	—	3.5 gpm
Pump Flow (Total)	—	6.3 GPM
Pump Flow (Steering)	—	3.5 gpm
Total Hydraulic Flow	—	6.3 gpm 23.8 lpm
Hydraulic System Type	—	Open center
Pump Flow (Implement)	—	3.5 gpm
System Operating Pressure	—	2000 PSI
Rear Remote Hydraulic Flow	—	3.5 gpm (13.3 lpm) implement circuit
Overall Hydraulic Pump Flow	—	6.3 gpm total (2.8 gpm steering + 3.5 gpm implement)
No. of Optional Remote Valves	—	1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs)

PTO Rear	—	540 rpm
PTO Type	—	independent
Lift Control Type	—	Position control (rockshaft lever)
Hitch Lift Capacity	—	1,433 lbs 1,433 lb
Mid PTO (Type / RPM)	—	Mid PTO Standard Equipment
Mid-PTO Availability	—	2100 rpm
Rear PTO (Type / RPM)	—	540-RPM Rear PTO
Category, 3-Point Hitch	—	Limited Category 1
Three-Point Hitch Category	—	Limited Category 1, 3-Pt. Hitch
Lift Capacity at 24 in Behind	—	758 lb
Hitch Lift Capacity (at 24”)	—	758 lb

R3 Turf - Rear	—	26x12-12
R3 Turf - Front	—	18x8.50-10
R4 Industrial - Rear	—	26x12-12
R4 Industrial - Front	—	18x8.5-10
R1 Agricultural - Rear	—	26x12-12
R1 Agricultural - Front	—	18x8.5-10

Coolant Capacity	—	0.98 gal
Crankcase Capacity	—	0.71 gal
Fuel Tank Capacity	—	5.6 gal
Front Axle Fluid Capacity	—	0.74 gal
Transmission/Hydraulic Capacity	—	3.3 gal
Transmission / Hydraulic System Capacity	—	3.3 gal

Loader Lift Height	—	71.2 in (D120 and H120 loaders)
Quick Attach Loader System	—	Quik-Park Loader System
Loader Lift Capacity (Full Height)	—	D120: 570 lb; H120: 512 lb (at full height, 71.2 in)

Clutch	—	Wet disk
No. of Speeds	—	Infinite (hydrostatic, 2-range)
Transmission Type	—	Hydrostatic - two range
Max Travel Speed (Forward)	—	9.1 mph
Max Travel Speed (Reverse)	—	9.1 mph
Differential Lock & Limited Slip Options	—	Differential lock Yes; Limited slip differential No

Brakes	—	Wet disc (left-hand pedal)
Steering	—	Power
Frame Type	—	Open center frame with two-post foldable ROPS
Front Axle Type	—	MFWD (Mechanical Front-Wheel Drive) 4WD
Front Axle Rating	—	1349 lb
Seat Suspension & Adjustability	—	Spring suspension seat, adjusts fore/aft

Wheelbase	—	57.1 in.
Overall Width	—	47.2 in with R3 tires; 47.3 in with R4 tires
Ground Clearance	—	7.7 in.
Height to Top of ROPS	—	78.6 in
Min. Turn Radius without Brakes	—	2.51 m 8.2 ft
Overall Length with 3-Point Hitch	—	87.6 in
