▶ EngineEngine Manufacturer John Deere Kubota Engine Model John Deere PowerTech 3029 V3307-CR-TE4 Engine Type Diesel, turbocharged, liquid-cooled Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 179 in³ 203 in³ Rated Engine Speed 2100 rpm 2400 rpm Engine Power (Gross) 67 hp 72.1 hp PTO Power 48.3 hp 62 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Two paper elements Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Not Published Common Rail System (CRS) Alternator 40 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 11.4 gpm HFC (2WD), HD/HDC (4WD): 11.0 gpm; HD12/HDC12 (4WD): 16.2 gpm Steering Flow 6.8 gpm 6.1 gpm Total Hydraulic Flow 18.2 gpm HFC (2WD), HD/HDC (4WD): 17.1 gpm; HD12/HDC12 (4WD): 22.3 gpm Overall Hydraulic Pump Flow 18.2 gpm HFC (2WD), HD/HDC (4WD): 17.1 gpm; HD12/HDC12 (4WD): 22.3 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published HFC (2WD), HD/HDC (4WD): 11.0 gpm; HD12/HDC12 (4WD): 16.2 gpm No. of Standard Remote Valves 1 1 (SCD) No. of Optional Remote Valves 2 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 19.6 gal ROPS: 18.5 gal; CAB: 23.8 gal Coolant Capacity 10 qt 8.5 qt Crankcase Capacity 9 qt 12.7 qt Transmission / Hydraulic System Capacity 2WD: 10 gal; 4WD: 10.3 gal 14.8 gal Front Axle Fluid Capacity 4.8 qt 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type OOS: independent, mechanical actuation; Cab: independent, mechanical or electrohydraulic actuation Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm (540E optional with PowrReverser) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I I / II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 3,192 lb 3,307 lb Lift Control Type Position control with top link draft sensing Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) Hydraulic-shuttle (F8/R8), fully synchronized (4-speed main) No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) F8/R8 Max Travel Speed (Forward) Not Published HFC (2WD), HD/HDC (4WD): 18.8 mph; HD12/HDC12 (4WD): 24.3 mph Max Travel Speed (Reverse) Not Published HFC (2WD), HD/HDC (4WD): 18.5 mph; HD12/HDC12 (4WD): 23.9 mph Clutch Dry (SyncShuttle); dry or wet (12F/12R PowrReverser) Multiple wet disc Differential Lock & Limited Slip Options Rear diff lock, standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Power steering Hydrostatic power steering Brakes Hydraulic wet disc brakes Mechanical wet disc Seat Suspension & Adjustability Not Published Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type 2WD or MFWD Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 137.8 in HFC (2WD): 142.7 in; HD/HDC (4WD), HD12/HDC12 (4WD): 138.0 in Overall Width 57.3 in 73.0 in Wheelbase 80.7 in HFC (2WD): 84.4 in; HD/HDC (4WD), HD12/HDC12 (4WD): 83.1 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in 18.1 in Min. Turn Radius without Brakes 138 in HFC (2WD): 10.8 ft; HD/HDC (4WD), HD12/HDC12 (4WD): 11.8 ft Height to Top of ROPS 98.4 in 97.2 in Height to Top of ROPS (folded) 78.5 in Not Published Height to Top of Cab Model 95.6 in 101.0 in ▶ WeightTractor Weight (Base) 2WD: 4,634 lb; MFWD: 5,621 lb 5,027 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard: 9.5-24 front, 16.9-30 rear R1 Agricultural - Front 2WD: 7.5-16; MFWD: 9.5-24 9.5-24 R1 Agricultural - Rear 16.9-28 16.9-30 R3 Turf - Front 9.5-16 (4WD) 9.5-24 or LSW305-521 R3 Turf - Rear 21.5L-16.1; 22.5LL-16.1 (Turf Special) 18.4-26 or LSW570-648 R4 Industrial - Front 12.5-80-18 (4WD) 14-17.5 R4 Industrial - Rear 16.9-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System H240 (NSL or MSL) LA1154A: 2-Lever Quick Coupler Loader Model H240NSL LA1154A Loader Lift Height 131 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) 3,671 lb Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force 4,504 lb Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
