▶ EngineEngine Manufacturer John Deere Daedong Engine Model 3029H 4HT-TP4A Engine Type Diesel, turbocharged Turbocharged diesel No. of Cylinders 3 4 Displacement 179 in³ 148.6 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 67.6 hp 66.4 hp PTO Power OOS: 53 hp; Cab: 49 hp 57.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Not Published Air Cleaner Dry type with safety element Not Published Fuel System Electronically controlled, high-pressure common rail Common rail Alternator OOS: 70 A; Cab: 110 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Implement Flow 11.4 gpm 11.0 gpm Steering Flow 6.8 gpm 6.9 gpm Total Hydraulic Flow 18.2 gpm 17.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 17.9 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal 22.5 gal Coolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) Not Published Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II Hitch Lift Capacity 3,968 lb Not Published Hitch Lift Capacity (at 24”) 3,192 lb 3594 lb Lift Control Type Position control, draft control, adjustable rate of drop Position with draft control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) 3-range powershuttle with electronic clutch No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 12 forward, 12 reverse Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 19.8 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 19.5 mph Clutch Dual clutch, 11 in (PowrReverser) Electronic clutch Differential Lock & Limited Slip Options Mechanical, rear Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering with tilt wheel Brakes Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Wet multi-disc Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Suspension seat, fully adjustable (standard) Front Axle Type 2WD or MFWD Four-wheel drive (standard) Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Drawbar Capacity Adjustable drawbar with interchangeable hitch balls Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 143.3 in 148.8 in Overall Width Not Published 77.2 in Wheelbase 80.7 in 82.7 in Ground Clearance Not Published 12.3 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD) 147.0 in Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 5,555 to 6,812 lb 5440 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow Industrial (standard), Agricultural, Multi-Use R1 Agricultural - Front 11L-15 9.5-24 R1 Agricultural - Rear 16.9-28 16.9-30 R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Not Published R3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) Not Published R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 12.5/80-18 R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System 512 or 520M Bob-Tach Loader Model 512 or 520M FL10 Loader Lift Height 512: 113 in; 520M: 132 in 129.3 in Loader Lift Capacity (Full Height) 512: 2,453 lb; 520M: 3,523 lb 2641 lb Loader Breakout Force 512: 4,781 lb; 520M: 4,641 lb Not Published ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 24 months or 1,500 hours (whichever occurs first); powertrain 36 months or 2,000 hours
