▶ EnginePTO Power 49 hp 51.1 hp Alternator 60 A, 12 V Not Published Air Cleaner Dry type with safety element Not Published Engine Type Diesel, turbocharged and aftercooled Diesel Fuel System Electronically controlled, high-pressure common rail Not Published Displacement 179 in³ 148.6 in³ No. of Cylinders 3 4 Rated Engine Speed 2100 rpm 2600 rpm Cooling System Type Liquid cooled with overflow reservoir Not Published Engine Manufacturer John Deere PowerTech 3029 EWR Daedong (4HT-TP4A) Engine Power (Gross) 68.6 hp @ 100 rpm 66.4 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 24 months / 1,500 hours (whichever occurs first) ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Steering Flow 6.8 gpm 6.9 gpm Implement Flow 11.4 gpm 11.0 gpm Total Hydraulic Flow 18.2 gpm 17.9 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published Overall Hydraulic Pump Flow 18.2 gpm 17.9 gpm No. of Optional Remote Valves 2 2 No. of Standard Remote Valves 1 1 ▶ PTO & HitchPTO Rear 540 @ 2083 engine rpm; 540E @ 1588 engine rpm 540/540E rpm PTO Type Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) Independent Lift Control Type Position and draft control; adjustable rate of drop Position with Draft Control Hitch Lift Capacity 3,968 lb @ hitch points Not Published Mid-PTO Availability Not Applicable Not Applicable Category, 3-Point Hitch Category II; convertible to Category I Category 2 Hitch Lift Capacity (at 24”) 3,197 lb @ 24 in behind hitch balls 3,594 lb @ 24 in behind lift point ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) Not Published R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Not Published Tire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow Industrial (Ag, Multi-Use) R4 Industrial - Rear 4.6 gal-24 8PR R4; 5.2 gal-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 18.4-24 (16.9-30, 480/80R26) R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 12.5/80-18 (9.5-24, 340/80R18) R1 Agricultural - Rear 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W Not Published R1 Agricultural - Front 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W Not Published ▶ Fluid CapacityCoolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Fuel Tank Capacity Open operator station: 15.6 ± 0.44 gal (71 ± 0.5 gal); Cab: 17.59 ± 0.44 gal (80 ± 0.5 gal) 25.1 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Not Published Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) Not Published ▶ Loader & AttachmentsLoader Lift Height 124 in 129.0 in Loader Breakout Force 4,354 lb (measured at pivot) Not Published Quick Attach Loader System Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Bob-Tach Loader Lift Capacity (Full Height) 3,225 lb (measured at pivot) 2,614 lb @ bucket pivot ▶ Transmission & DrivetrainClutch Dual clutch, 11 in (PowrReverser) Electronic Clutch No. of Speeds 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) 12x12 Transmission Type SyncShuttle 9F/3R (standard); PowrReverser 12F/12R (optional) 3-Range Powershuttle with Electronic Clutch Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 19.8 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 19.5 mph Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsBrakes Hydraulically actuated wet disk brakes (oil-immersed) Wet Multi-Disc Steering Hydrostatic power steering Not Published Frame Type Not Published Not Published Front Axle Type 2WD (standard) or MFWD (optional) Not Published Drawbar Capacity 1,675 lb (fully extended); 2,470 lb (short position) Not Published Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Not Published ▶ Dimensions & ManeuverabilityWheelbase 80.7 in 82.7 in Overall Width Not Published 77.2 in Ground Clearance Not Published 12.3 in Height to Top of ROPS Not Published Not Applicable Height to Top of Cab Model Not Published 99.3 in Height to Top of ROPS (folded) Not Published Not Applicable Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD) 147.0 in Overall Length with 3-Point Hitch 143.3 in 148.8 in
