▶ EngineEngine Manufacturer John Deere Yanmar Engine Model 3029H 4TNV86CHT-MJT Engine Type Diesel, turbocharged Turbocharged 4-cylinder Diesel No. of Cylinders 3 4 Displacement 179 in³ 127.6 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 67.6 hp 65.9 hp PTO Power OOS: 53 hp; Cab: 49 hp 51.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Liquid Air Cleaner Dry type with safety element Dual element Fuel System Electronically controlled, high-pressure common rail High-pressure common rail direct injection Alternator OOS: 70 A; Cab: 110 A 75 A, 12 V ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Dual Independent Implement Flow 11.4 gpm 10.2 gpm Steering Flow 6.8 gpm 5.7 gpm Total Hydraulic Flow 18.2 gpm 15.9 gpm Overall Hydraulic Pump Flow 18.2 gpm 15.9 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal Open station: 15.0 gal; Cab: 14.7 gal (if equipped) Coolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal Open station: 6.8 qt; Cab: 8.0 qt (if equipped) Crankcase Capacity 9.0 qt (with filter) 5.6 qt (with filter) Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) 12.5 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side 5.3 qt ▶ PTO & HitchPTO Type Independent Independent (electrohydraulic) PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II, convertible to I Category I/II Hitch Lift Capacity 3,968 lb 3,130 lb Hitch Lift Capacity (at 24”) 3,192 lb 2,500 lb Lift Control Type Position control, draft control, adjustable rate of drop Position control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) eHydro (3-range hydrostatic); no PowrReverser gear option offered No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) eHydro: Infinitely-variable, 3 range Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 18.6 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 18.6 mph Clutch Dual clutch, 11 in (PowrReverser) Wet; wet clutch disk diameter 5.08 in Differential Lock & Limited Slip Options Mechanical, rear Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published ROPS - Foldable Steering Hydrostatic power steering Power steering (hydrostatic) Brakes Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Wet disc Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Not Published Front Axle Type 2WD or MFWD Mechanical front wheel drive (MFWD) - Standard Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) (Continuous) 3307 lb Drawbar Capacity Adjustable drawbar with interchangeable hitch balls Max vertical load 1103 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 143.3 in 134.7 in Overall Width Not Published 71.3 in Wheelbase 80.7 in 73.0 in Ground Clearance Not Published Front axle: 15.2 in; Drawbar support: 14.5 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD) 17.1 ft (5.2 m) Height to Top of ROPS Not Published 91.1 in Height to Top of ROPS (folded) Not Published 65.9 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 5,555 to 6,812 lb 4,255 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial R1 Agricultural - Front 11L-15 Not Published R1 Agricultural - Rear 16.9-28 Not Published R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Not Published R3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) Not Published R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 31.5x13-16.5 (10PR) R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 512 or 520M Rigid mounted with parking kit available; Parking stand kit BW16127 (parkable) Loader Model 512 or 520M 440R (Quik-Park) Loader Lift Height 512: 113 in; 520M: 132 in 110 in Loader Lift Capacity (Full Height) 512: 2,453 lb; 520M: 3,523 lb 2,539 lb (at pivot, NSL) Loader Breakout Force 512: 4,781 lb; 520M: 4,641 lb At pivot: 3,853 lbf; @ 19.7 in ahead of pivot: 2,902 lbf ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
