▶ EngineEngine Manufacturer John Deere John Deere John Deere Engine Model PowerTech 3029 (2.9L) EWR PowerTech 3029 (2.9L) EWR PowerTech 3029 (2.9L) EWR Engine Type Diesel, turbocharged Diesel, turbocharged Diesel, turbocharged No. of Cylinders 3 3 3 Displacement 179 in³ 179 in³ 179 in³ Rated Engine Speed 2100 rpm 2100 rpm 2100 rpm Engine Power (Gross) 67.6 hp 60 hp 73.7 hp PTO Power PR/TSS OOS: 55.3 hp; PR/TSS Cab: 53.3 hp; eHydro: 44.5 hp PR/TSS OOS: 48.3 hp; PR/TSS Cab: 46.3 hp; eHydro: 38.3 hp PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp Engine Emissions Constraints Tier 4 Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type with safety element Dry type with safety element Fuel System Electronically controlled, high-pressure common rail Electronically controlled, high-pressure common rail Electronically controlled, high-pressure common rail Alternator 110 A 110 A 110 A ▶ HydraulicsPump Type PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 11.4 gpm 11.4 gpm 11.4 gpm Steering Flow 6.8 gpm 6.8 gpm 6.8 gpm Total Hydraulic Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open Center Open Center Open Center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV 11.4 gpm at a single rear SCV 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 1 1 No. of Optional Remote Valves Not Published 2 2 ▶ Fluid CapacityFuel Tank Capacity OOS: 19 gal; Cab: 21 gal OOS: 19 gal; Cab: 21 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity Not Published Not Published Not Published Crankcase Capacity 9.0 qt (with filter) 9.0 qt (with filter) 9.0 qt (with filter) Transmission / Hydraulic System Capacity Not Published Not Published Not Published Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent Independent PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II, convertible to I Category II, convertible to I Hitch Lift Capacity 3,968 lb 3,968 lb 3,968 lb @ hitch points Hitch Lift Capacity (at 24”) 3,192 lb 3,192 lb 3,192 lb Lift Control Type Position control, draft control, adjustable rate of drop Position control, draft control, adjustable rate of drop Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser or eHydro (optional) SyncShuttle (standard); PowrReverser or eHydro (optional) SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 15.5 mph (SyncShuttle) 15.5 mph (SyncShuttle) 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) Not Published Not Published Not Published Clutch SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Mechanical, rear Mechanical, rear Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Not Published Not Published Not Published Front Axle Type 2WD or MFWD 2WD or MFWD 2WD or MFWD Front Axle Rating Not Published Not Published Not Published Drawbar Capacity Adjustable drawbar with interchangeable hitch balls 1,675 lb (fully extended); 2,470 lb (short position) Adjustable drawbar ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Not Published Wheelbase 80.7 in 80.7 in 80.7 in Ground Clearance Not Published Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) 11.5 ft (2WD); 15.3 ft (MFWD) 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS Not Published Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Not Published Height to Top of Cab Model Not Published Not Published Not Published Overall Length 144.5 in 144.5 in 144.5 in ▶ WeightTractor Weight (Base) 5,555 to 6,812 lb (shipping weight) 5,445 to 6,702 lb (shipping weight) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Not Published Weight with Cab and Loader Not Published Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published Not Published R1 Agricultural - Front MFWD: 11.2-24; 12.4-24 MFWD: 9.5-24; 11.2-24; 12.4-24 MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear 16.9-28 14.9-28 16.9-28 R3 Turf - Front Not Published Not Published Not Published R3 Turf - Rear Not Published Not Published Not Published R4 Industrial - Front Not Published Not Published Not Published R4 Industrial - Rear Not Published Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model 500E, 500M or 520M 500E, 500M or 520M 500E, 500M or 520M Loader Lift Height 500M: 124 in 500M: 124 in 500M: 124 in Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 500M: 3,225 lb (at pivot, full height) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force 500M: 4,354 lb (at pivot) 500M: 4,354 lb (at pivot) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published Not Published
