▶ EngineEngine Manufacturer John Deere KIOTI Engine Model 3029H 4H243T Engine Type Diesel, turbocharged In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4H243T) No. of Cylinders 3 4 Displacement 179 in³ 148.6 in³ Rated Engine Speed 2100 rpm 2600 rpm Engine Power (Gross) 67.6 hp 66.4 hp PTO Power OOS: 53 hp; Cab: 49 hp 54.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled with overflow reservoir Water-cooled Air Cleaner Dry type with safety element Not Published Fuel System Electronically controlled, high-pressure common rail Common Rail Direct Injection (CRDI) Alternator OOS: 70 A; Cab: 110 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Tandem Gear Implement Flow 11.4 gpm 12.4 gpm Steering Flow 6.8 gpm 8.2 gpm Total Hydraulic Flow 18.2 gpm 20.6 gpm Overall Hydraulic Pump Flow 18.2 gpm 20.6 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity OOS: 19.6 gal; Cab: 21.6 gal 26.4 gal Coolant Capacity Open operator station: 2.85 gal; Cab: 3.08 gal 2.51 gal Crankcase Capacity 9.0 qt (with filter) 2.83 gal Transmission / Hydraulic System Capacity 8.36 gal (9x3); 9.46 gal (12x12) 11.75 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side 2.6 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 / 540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II Hitch Lift Capacity 3,968 lb 5,584.3 lb Hitch Lift Capacity (at 24”) 3,192 lb 4,327.7 lb Lift Control Type Position control, draft control, adjustable rate of drop Electronic Control ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser (optional) Manual: Power Shuttle No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 12 forward / 12 reverse Max Travel Speed (Forward) 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) 22.01 mph Max Travel Speed (Reverse) 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) 21.92 mph Clutch Dual clutch, 11 in (PowrReverser) Wet Disc Differential Lock & Limited Slip Options Mechanical, rear Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Wet Multi Disc Seat Suspension & Adjustability Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Adjustable Air-Ride Seat Front Axle Type 2WD or MFWD Not Published Front Axle Rating Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Not Published Drawbar Capacity Adjustable drawbar with interchangeable hitch balls 1,984 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 143.3 in 150.3 in Overall Width Not Published 82.1 in Wheelbase 80.7 in 85.4 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes 137.8 in (2WD); 183.1 in (4WD) 12.8 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 105.3 in ▶ WeightTractor Weight (Base) 5,555 to 6,812 lb 6,814.5 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural, R4 Industrial R1 Agricultural - Front 11L-15 11.2-24 R1 Agricultural - Rear 16.9-28 16.9-30 R3 Turf - Front 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Not Published R3 Turf - Rear 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) Not Published R4 Industrial - Front 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 12.5/80-18 R4 Industrial - Rear 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 18.4-24/8 ▶ Loader & AttachmentsQuick Attach Loader System 512 or 520M Built-in parking stand; designed to be quickly and easily attached and detached. Loader Model 512 or 520M KL7340 Loader Lift Height 512: 113 in; 520M: 132 in KL7340: 127.1 in (to pivot pin) Loader Lift Capacity (Full Height) 512: 2,453 lb; 520M: 3,523 lb KL7340: 3,300 lb (at pivot pin, full height) Loader Breakout Force 512: 4,781 lb; 520M: 4,641 lb KL7340: 5,875.3 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Tractors (Non-Commercial Application): 24 months parts & labor; Extended (Non-Commercial, driveline/powertrain): 48 months parts & labor; Limited time: eligible units receive total 6 years (72 months) extended powertrain warranty coverage.
