▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 3029 (2.9L) EWR John Deere PowerTech 3029 Engine Type Diesel, turbocharged Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2100 rpm 2100 rpm Engine Power (Gross) 73.7 hp 67 hp PTO Power PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp 49 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Dry type, dual element (primary and secondary) Fuel System Electronically controlled, high-pressure common rail Not Published Alternator 110 A 40 A ▶ HydraulicsPump Type PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Not Published Implement Flow 11.4 gpm 11.4 gpm Steering Flow 6.8 gpm 6.8 gpm Total Hydraulic Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 18.2 gpm Overall Hydraulic Pump Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 18.2 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity OOS: 19 gal; Cab: 21 gal 19.6 gal Coolant Capacity Not Published 10 qt Crankcase Capacity 9.0 qt (with filter) 9 qt Transmission / Hydraulic System Capacity Not Published 10.3 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Independent Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II, convertible to I Hitch Lift Capacity 3,968 lb @ hitch points Not Published Hitch Lift Capacity (at 24”) 3,192 lb 3,192 lb Lift Control Type Position control, draft control, adjustable rate of drop Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser or eHydro (optional) SyncShuttle (standard); PowrReverser (optional) No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 15.5 mph (SyncShuttle) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Mechanical, rear Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Hydraulic wet disc brakes Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD or MFWD 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Adjustable drawbar 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width Not Published 57.3 in Wheelbase 80.7 in 80.7 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS Not Published 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model Not Published 95.6 in Overall Length 144.5 in 137.8 in ▶ WeightTractor Weight (Base) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front MFWD: 11.2-24; 12.4-24 MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 16.9-28 16.9-28 R3 Turf - Front Not Published 9.5-16 (MFWD) R3 Turf - Rear Not Published 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front Not Published 12.5/80-18 (MFWD) R4 Industrial - Rear Not Published 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader 520M; H240 (NSL or MSL) Loader Model 500E, 500M or 520M H240NSL Loader Lift Height 500M: 124 in 131 in Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 3,671 lb (H240NSL, at pivot) Loader Breakout Force 500M: 4,354 lb (at pivot) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
