▶ EngineEngine Manufacturer John Deere AGCO Power Engine Model PowerTech 3029 (2.9L) EWR 33 AWIC Engine Type Diesel, turbocharged 3-cylinder, intercooled turbocharged diesel No. of Cylinders 3 3 Displacement 179 in³ 201.4 in³ Rated Engine Speed 2100 rpm 2200 rpm Engine Power (Gross) 73.7 hp 75 hp PTO Power PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry type with safety element Dual element (primary and secondary) Fuel System Electronically controlled, high-pressure common rail High-pressure common rail direct fuel injection Alternator 110 A 80 A ▶ HydraulicsPump Type PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Two-stage pump Implement Flow 11.4 gpm Not Published Steering Flow 6.8 gpm Not Published Total Hydraulic Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Not Published Overall Hydraulic Pump Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Not Published Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV 17.2 gpm No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity OOS: 19 gal; Cab: 21 gal 33 gal Coolant Capacity Not Published 4.2 gal Crankcase Capacity 9.0 qt (with filter) 3.3 gal Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Independent Independent, electrohydraulic engagement PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category II Hitch Lift Capacity 3,968 lb @ hitch points Not Published Hitch Lift Capacity (at 24”) 3,192 lb 4,850 lb Lift Control Type Position control, draft control, adjustable rate of drop Not Published ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser or eHydro (optional) 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) 15.5 mph (SyncShuttle) 2WD: 18 mph; 4WD: 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Mechanical, rear Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Not Published Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Front Axle Type 2WD or MFWD Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Adjustable drawbar Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 80.7 in 88.5 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in Not Published Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 144.5 in Not Published ▶ WeightTractor Weight (Base) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Rear: 420/85R30 standard R1 Agricultural - Front MFWD: 11.2-24; 12.4-24 2WD: 9.5L-15; 4WD: 320/85R24 R1 Agricultural - Rear 16.9-28 420/85R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader 931X and 936X: universal skid steer type quick release Loader Model 500E, 500M or 520M FL.3522, FL.3615, 931X, 936X Loader Lift Height 500M: 124 in FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force 500M: 4,354 lb (at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
