▶ EngineEngine Manufacturer John Deere Not Published Engine Model PowerTech 3029 (2.9L) EWR S8000 Engine Type Diesel, turbocharged Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 73.7 hp 74 hp PTO Power PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry type with safety element Not Published Fuel System Electronically controlled, high-pressure common rail Common rail fuel injection Alternator 110 A Not Published ▶ HydraulicsPump Type PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Dual-pump Implement Flow 11.4 gpm 12.6 gpm Steering Flow 6.8 gpm 7.6 gpm Total Hydraulic Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 20.2 gpm Overall Hydraulic Pump Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 20.2 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 3 ▶ Fluid CapacityFuel Tank Capacity OOS: 19 gal; Cab: 21 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540/540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Not Published Hitch Lift Capacity 3,968 lb @ hitch points Not Published Hitch Lift Capacity (at 24”) 3,192 lb 4,000 lb Lift Control Type Position control, draft control, adjustable rate of drop Lift-O-Matic ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser or eHydro (optional) 12x12 Mechanical Shuttle No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 12F/12R Max Travel Speed (Forward) 15.5 mph (SyncShuttle) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Not Published Differential Lock & Limited Slip Options Mechanical, rear Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Straddle-deck platform Steering Hydrostatic power steering Not Published Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Not Published Seat Suspension & Adjustability Not Published Vinyl suspension seat Front Axle Type 2WD or MFWD 4WD front axle, electronic engagement Front Axle Rating Not Published Not Published Drawbar Capacity Adjustable drawbar Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 57 in Wheelbase 80.7 in 73 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in Not Published Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) Not Published Height to Top of ROPS Not Published 97 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 144.5 in 143 in ▶ WeightTractor Weight (Base) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) 5,000 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front MFWD: 11.2-24; 12.4-24 Not Published R1 Agricultural - Rear 16.9-28 320/70R20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Not Published Loader Model 500E, 500M or 520M Not Published Loader Lift Height 500M: 124 in Not Published Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) Not Published Loader Breakout Force 500M: 4,354 lb (at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
