▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 3029 (2.9L) EWR S8000 Engine Type Diesel, turbocharged Turbocharged 3-cylinder diesel No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 73.7 hp 74 hp PTO Power PR/TSS OOS: 57 hp; PR/TSS Cab: 55 hp; eHydro: 51.4 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid-cooled Not Published Air Cleaner Dry type with safety element PowerCore dry air cleaner Fuel System Electronically controlled, high-pressure common rail Bosch electronic high-pressure common rail Alternator 110 A 120 A ▶ HydraulicsPump Type PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Dual gear pumps Implement Flow 11.4 gpm 12.6 gpm Steering Flow 6.8 gpm 7.6 gpm Total Hydraulic Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 20.2 gpm Overall Hydraulic Pump Flow PR/TSS: 18.2 gpm; eHydro: 29.6 gpm 20.2 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow 11.4 gpm at a single rear SCV Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity OOS: 19 gal; Cab: 21 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity 9.0 qt (with filter) Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side Not Published ▶ PTO & HitchPTO Type Independent Fully independent, hydraulic wet clutch PTO Rear 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II, convertible to I Category I/II Hitch Lift Capacity 3,968 lb @ hitch points Not Published Hitch Lift Capacity (at 24”) 3,192 lb 3,500 lb Lift Control Type Position control, draft control, adjustable rate of drop Mechanical draft control (upper-link draft sensing) ▶ Transmission & DrivetrainTransmission Type SyncShuttle (standard); PowrReverser or eHydro (optional) 12x12 hydraulic power shuttle No. of Speeds 9F/3R (SyncShuttle); 12F/12R (PowrReverser) 12F/12R Max Travel Speed (Forward) 15.5 mph (SyncShuttle) 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic 11 in single dry disc Differential Lock & Limited Slip Options Mechanical, rear Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Hydraulic-assist wet brakes Seat Suspension & Adjustability Not Published Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: mechanical vinyl suspension seat Front Axle Type 2WD or MFWD 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Front Axle Rating Not Published 6,500 lb dynamic capacity Drawbar Capacity Adjustable drawbar Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published Not Published Wheelbase 80.7 in 83.6 in Ground Clearance 2WD: 18.8 in; MFWD: 13.4 in Not Published Min. Turn Radius without Brakes 11.5 ft (2WD); 15.3 ft (MFWD) Not Published Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 100.2 in Overall Length 144.5 in 154.1 in ▶ WeightTractor Weight (Base) OOS 2WD: 5,555 lb; OOS MFWD: 6,029 lb; Cab 2WD: 6,590 lb; Cab MFWD: 6,812 lb (shipping weight) ROPS: 6,250 lb; Cab: 6,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) R1 Agricultural - Front MFWD: 11.2-24; 12.4-24 11.2x24 R1, 6 ply R1 Agricultural - Rear 16.9-28 16.9x30 R1, 6 ply R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4, 10 ply R4 Industrial - Rear Not Published 19.5L-24 R4, 10 ply ▶ Loader & AttachmentsQuick Attach Loader System 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader 72 in bucket with SSL (skid steer) or Euro-style quick attach Loader Model 500E, 500M or 520M 550LU (non self-leveling); 555LU (mechanical self-leveling) Loader Lift Height 500M: 124 in 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) Loader Lift Capacity (Full Height) 500M: 3,225 lb (at pivot, full height) 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) Loader Breakout Force 500M: 4,354 lb (at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
